SANDPIPER SSA2-A - Manual (Page 13)

ssa2dl4sm-REV0614 Model SSA2-A Page 11
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
34 560-020-360 O-Ring 6
35 031-012-000 Sleeve & Spool Set 1
36 132-014-358 Bumper, Spool 2
37 360-010-425 Gasket, End Cap 2
38 165-011-332 Cap, End 2
39 170-032-115 Capscrew, Hex Hd. 8
40 170-045-115 Capscrew, Hex Hd. 4
41 095-047-332 Body Valve 1
42 807-044-115 Stud 8
43 406-003-000 Knob, Locking 8
45 405-007-115 Handle (fits on P/N 196-041-xxx)
46 132-022-360 Bumper 2
47 612-197-111 Plate, Outer Diaphragm 2
612-197-113 Plate, Outer Diaphragm 2
Repair Parts Not Shown:
893-057-332 Valve, Angle 3 1
538-025-335 Nipple, Pipe 3 1
031-019-332 Valve Body Ass'y 1
(consists of items: 34-39, 41) 1
535-015-000 Name Plate 1
705-002-000 Drive Screw 4
1 Available in kit form. Order P/N 031-055-000 which also includes
items 9, 31, 33, 46.
2 Items 26 thru 30 may be ordered individually, or as a kit: #476-051-
000. It is recommended that four kits (required for each pump) be
purchased and replaced at the same time.
3 These items are available in Kit Form Only. They are no longer
included on standard units. Order as Angle Valve Kit #475-115-000.
Repair Parts shown in bold face (darker) type are more
likely to need replacement after extended periods of
normal use.
They are readily available from most Warren Rupp
distributors. The pump owner may prefer to maintain a
limited inventory of these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts always furnish
pump model number, serial number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000... Assembly, sub-assembly; and some
purchased items
010... Cast Iron
015... Ductile Iron
025... Music Wire
080... Carbon Steel, AISI B-1112
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
114... 303 Stainless Steel
115... 301/302/304 Stainless Steel
120... 416 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —
Duro 40D +/-5; Color: RED
356... Hytrel
357... Rupplon (Urethane Rubber)
360... Buna-N Rubber. Color coded: RED
363... Viton (Fluorel). Color coded: YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Nitrile. Color coded: WHITE
375... Fluorinated Nitrile
405... Cellulose Fibre
408... Cork and Neoprene
425... Compressed Fibre
440... Vegetable Fibre
500... Delrin 500
501... Delrin 570
520... Injection Molded PVDF, Natural Color,
Food Grade/USDA Acceptable
540... Nylon
550... Polyethylene
551... Polypropylene
555... PVC (Polyvinyl Chloride)
580... Ryton
600... Teflon (virgin material) Tetrafluoroethylene (TFE)
603... Blue Gylon
604... Teflon — Diaphragm
610... Encapsulated Silicon
611... Teflon Encapsulated Viton
Delrin, Teflon, Hytrel, and Viton are
registered tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock, Inc.
Rupplon and SandPIPER are registered
tradenames of Warren Rupp, Inc.
Ryton is a registered tradename of Phillips
Chemical Company.
Loctite is a registered tradename of Loctite Corporation.
