Composite repair parts list, Model specific, Exp view – SANDPIPER G30 User Manual
Page 12
sandpiperpump
.
com
9
• Model G30 Metallic
g30mdl1sm-rev0614
Item
Part Number
Description
Qty
23
518-144-110
Manifold, Discharge
1
518-144-110E
Manifold, Discharge 3" BSP Tapered
1
518-144-156
Manifold, Discharge
1
518-144-156E
Manifold, Discharge 3" BSP Tapered
1
518-172-110
Manifold, ANSI Flange Discharge
1
518-172-110E
Manifold, DIN Flange Discharge
1
518-172-156
Manifold, ANSI Flange Discharge
1
518-172-156E
Manifold, DIN Flange Discharge
1
24
545-007-330
Nut, Hex 7/16-14
16
545-007-115
Nut, Hex 7/16-14
16
545-007-110
Nut, Hex 7/16-14 (SS Mid Section)
16
25
545-008-330
Nut, Hex 1/2-13
16
545-008-110
Nut, Hex 1/2-13 (SS Mid Section)
16
26
560-001-360
O-Ring
2
560-001-363
O-Ring
2
28
612-195-157
Plate, Inner Diaphragm
2
612-195-334
Plate, Inner Diaphragm (SS Mid Section) 2
29
612-194-156
Plate, Outer Diaphragm Assembly
2
612-194-110
Plate, Outer Diaphragm Assembly
2
30
620-020-115
Plunger, Actuator
2
31
675-042-115
Ring, Retaining
2
32
685-040-110
Rod, Diaphragm
1
33
720-004-360
Seal, Diaphragm Rod
2
720-004-363
Seal, Diaphragm Rod
2
34
722-090-360
Seat, Check Ball
4
(seals required see Items 36)
722-090-600
Seat, Check Ball
4
(seals required see Items 36)
722-090-110
Seat, Check Ball
4
(seals required see Items 36)
722-090-150
Seat, Check Ball
4
(seals required see Items 36)
35
920-025-000
Ground Strap
1
36
560-105-360
Seal (use with metal seats)
8
720-055-608
Seal (use metal with seats)
8
37
901-038-330
Flat Washer
4
901-038-110
Flat Washer
4
901-038-115
Flat Washer
4
Item
Part Number
Description
Qty
1
031-183-000
Gas Valve Assembly
1
031-183-363
Gas Valve Assembly
1
031-179-000
Gas Valve Assembly (SS Mid Section)
1
031-179-363
Gas Valve Assembly (SS Mid Section)
1
2
050-014-360
Ball, Check
4
050-015-600
Ball, Check
4
3
070-006-170
Bushing
2
4
095-110-000
Pilot Valve Assembly
1
095-110-363
Pilot Valve Assembly
1
095-110-110
Pilot Valve Assembly (SS Mid Section) 1
095-110-363SS
Pilot Valve Assembly (SS Mid Section) 1
5
114-024-157
Intermediate Bracket
1
6
132-035-360
Bumper, Diaphragm
2
132-035-363
Bumper, Diaphragm
2
7
135-034-506
Bushing, Plunger
2
8
165-113-157
Cap, Inlet Assembly
1
165-113-110
Cap, Inlet Assembly (SS Mid Section)
1
9
170-006-330
Capscrew, Hex Hd 3/8-16 X 1.00
4
170-006-115
Capscrew, Hex Hd 3/8-16 X 1.00
4
170-006-110
Capscrew, Hex Hd 3/8-16 X 1.00
4
(SS Mid Section)
10
170-055-330
Capscrew, Hex Hd 1/2-13 X 2.50
16
170-055-115
Capscrew, Hex Hd 1/2-13 X 2.50
16
170-055-110
Capscrew, Hex Hd 1/2-13 X 2.50
16
(SS Mid Section)
11
170-060-330
Capscrew, Hex Hd 7/16-14 X 2.00
16
170-060-115
Capscrew, Hex Hd 7/16-14 X 2.00
16
170-060-110
Capscrew, Hex Hd 7/16-14 X 2.00
16
(SS Mid Section)
12
170-069-330
Capscrew, Hex Hd 5/16-18 X 1.75
4
170-069-115
Capscrew, Hex Hd 5/16-18 X 1.75
4
170-069-110
Capscrew, Hex Hd 5/16-18 X 1.75
4
(SS Mid Section)
13
171-059-330
Capscrew, Soc Hd 7/16-14 X 1.25
8
171-011-115
Capscrew, Soc Hd 1/2-13 X 1.00
8
171-011-110
Capscrew, Soc Hd 1/2-13 X 1.00
8
(SS Mid Section)
14
196-164-156
Chamber, Outer
2
196-164-110
Chamber, Outer
2
15
196-165-157
Chamber, Inner
2
196-165-110
Chamber, Inner (SS Mid Section)
2
16
286-098-360
Diaphragm
2
17
286-098-604
Diaphragm, Overlay
2
18
360-093-360
Gasket, Natural Gas Valve
1
19
360-103-360
Gasket, Pilot Valve
1
20
360-104-379
Gasket, Natural Gas Inlet
1
21
360-105-360
Gasket, Inner Chamber
2
22
518-143-110
Manifold, Suction
1
518-143-110E
Manifold, Suction 3" BSP Tapered
1
518-143-156
Manifold, Suction
1
518-143-156E
Manifold, Suction 3" BSP Tapered
1
518-171-110
Manifold, ANSI Flange Suction
1
518-171-110E
Manifold, DIN Flange Suction
1
518-171-156
Manifold, ANSI Flange Suction
1
518-171-156E
Manifold, DIN Flange Suction
1
Composite Repair Parts List
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
MODEL SPECIFIC
3: EXP
VIEW
