• Model G20 Metallic
g20mdl1sm-rev0614
Composite Repair Parts List
ATEX Compliant
LEGEND:
= Items contained within Gas End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
Item Part Number
Description
Qty.
1
031-183-000
Aluminum Gas Valve Assembly
1
031-183-363
Aluminum Gas Valve Assembly with FKM O-rings 1
031-179-000
Stainless Steel Gas Valve Assembly
(use with Option B)
1
031-179-363
Stainless Steel Gas Valve Assembly
with FKM O-rings (used with Option D)
1
2
050-017-360
Ball, Check
4
050-018-600
Ball, Check
4
3
070-006-170
Bushing
2
4
095-110-000
Pilot Valve Assembly
1
095-110-363
Pilot Valve Assembly with FKM O-rings
1
095-110-110
Pilot Valve Assembly (Stainless Steel Midsection) 1
095-110-363SS Pilot Valve Assembly with FKM O-rings
(Stainless Steel Midsection)
1
5
114-024-157
Intermediate Bracket
1
114-024-110
Intermediate Bracket (Stainless Steel Midsection) 1
6
132-035-360
Bumper, Diaphragm
2
132-035-363
Bumper, Diaphragm
2
7
135-034-506
Bushing, Plunger
2
8
165-116-157
Cap, Gas Inlet Assembly
1
165-116-110
Cap, Gas Inlet Assembly
(Stainless Steel Midsection)
1
9
170-060-330
Capscrew, Hex Hd 7/16-14 X 2.00
16
170-060-115
Capscrew, Hex Hd 7/16-14 X 2.00
16
170-060-110
Capscrew, Hex Hd 7/16-14 X 2.00
16
(Stainless Steel Midsection)
10
170-052-330
Capscrew, Hex Hd 3/8-16 X 2.25
16
170-052-115
Capscrew, Hex Hd 3/8-16 X 2.25
16
170-052-110
Capscrew, Hex Hd 3/8-16 X 2.25
16
(Stainless Steel Midsection)
11
170-069-330
Capscrew, Hex Hd 5/16-18 X 1.75
4
170-069-115
Capscrew, Hex Hd 5/16-18 X 1.75
4
170-069-110
Capscrew, Hex Hd 5/16-18 X 1.75
4
(Stainless Steel Midsection)
12
170-006-330
Capscrew, Hex Hd 3/8-16 X 1.00
4
170-006-115
Capscrew, Hex Hd 3/8-16 X 1.00
4
170-006-110
Capscrew, Hex Hd 3/8-16 X 1.00
4
(Stainless Steel Midsection)
13
171-059-330
Capscrew, Soc Hd 7/16-14 X 1.25
8
171-011-115
Capscrew, Soc Hd 1/2-13 X 1.00
8
171-011-110
Capscrew, Soc Hd 1/2-13 X 1.00
8
(Stainless Steel Midsection)
14
196-167-156
Chamber, Outer
2
196-167-110
Chamber, Outer
2
15
196-168-156
Chamber, Inner
2
196-168-110
Chamber, Inner (Stainless Steel Midsection)
2
16
286-007-360
Diaphragm
2
17
286-020-604
Diaphragm, Overlay
2
18
360-093-360
Gasket, Natural Gas Valve
1
19
360-103-360
Gasket, Pilot Valve
1
20
360-104-379
Gasket, Natural Gas Inlet
1
21
360-105-360
Gasket, Inner Chamber
2
22
518-145-156
Manifold, Suction
1
518-145-156E Manifold, Suction 2" BSP
1
518-145-156W Welded Raised Face 150#
2" ANSI Flanged Manifold
1
518-145-110
Manifold, Suction
1
518-145-110E Manifold, Suction 2" BSP
1
518-145-110W Welded Raised Face 150#
2" ANSI Flanged Manifold
1
Item Part Number
Description
Qty.
23
518-146-156
Manifold, Discharge
1
518-146-156E Manifold, Discharge 2" BSP
1
518-146-156W Welded Raised Face 150#
2" ANSI Flanged Manifold
1
518-146-110
Manifold, Discharge
1
518-146-110E Manifold, Discharge 2" BSP
1
518-146-110W Welded Raised Face 150#
2" ANSI Flanged Manifold
1
24
545-005-330
Nut, Hex 3/8-16
16
545-005-115
Nut, Hex 3/8-16
16
545-005-110
Nut, Hex 3/8-16 (Stainless Steel Midsection)
16
25
545-007-330
Nut, Hex 7/16-14
16
545-007-115
Nut, Hex 7/16-14
16
545-007-110
Nut, Hex 7/16-14 (Stainless Steel Midsection) 16
26
560-001-360
O-Ring
2
560-001-363
O-Ring
2
28
612-192-157
Plate, Inner Diaphragm
2
612-192-334
Plate, Inner Diaphragm (Stainless Steel Midsection) 2
29
612-194-156
Plate, Outer Diaphragm Assembly
2
612-194-110
Plate, Outer Diaphragm Assembly
2
30
612-195-157
Plate, Inner Diaphragm (PTFE overlays only)
2
612-195-334
Plate, Inner Diaphragm (Stainless Steel Midsection) 2
31
612-039-157
Plate, Outer Diaphragm (PTFE overlays only)
2
612-097-110
Plate, Diaphragm (PTFE overlays only)
2
32
620-020-115
Plunger, Actuator
2
33
675-042-115
Ring, Retaining
2
34
685-058-110
Rod, Diaphragm
1
35
720-004-360
Seal, Diaphragm Rod
2
720-004-363
Seal, Diaphragm Rod
2
36
722-040-360
Seat, Check Ball
4
722-040-600
Seat, Check Ball
4
722-040-110
Seat, Ckeck Ball (requires seals, see item 39)
4
722-040-150
Seat, Ckeck Ball (requires seals, see item 39)
4
37
900-005-330
Washer, Lock
16
900-005-115
Washer, Lock
16
900-005-110
Washer, Lock (Stainless Steel Midsection)
16
38
920-025-000
Ground Strap
1
39
560-106-360
O-Ring (use with metal seats)
8
720-060-608
Seal (use with metal seats)
8
40
901-038-330
Flat Washer
4
901-038-110
Flat Washer
4
901-038-115
Flat Washer
4
Parts not shown used with Raised Face ANSI Flange Options R and W:
170.035.330 Hex Cap Screw
4
326.052.080 Mounting Foot
2
545.007.330 Hex Nut
4
900.006.330 Lock Washer
4
901.022.330 Flat Washer
8
Parts not shown used with Raised Face ANSI Flange Option R ONLY:
334.115.110 2" ANSI 150# Raised Face Flange
and Threaded Pipe Connection
2
538.024.110 2" NPT Pipe Nipple x 2 1/2" Long
2
