SANDPIPER GH2 - Manual (Page 6)

Model GH2 Page 6 gh2dl1sm-REV0714
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD. Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most War-
ren Rupp distributors. The pump owner
may prefer to maintain a limited inventory
of these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
Continued from previous page
375…Fluorinated Nitrile
378…High density Polypropylene
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
426…Blue Gard
440…Vegetable Fibre
465…Fibre
500…Delrin 500
501…Delrin 570
505…Acrylic Resin Plastic
520…Injection Molded PVDF Natural Color
540…Nylon
541…Nylon
542…Nylon
544…Nylon Injection Molded
550…Polyethylene
551…Polypropylene
552…Unfilled Polypropylene
553…Unfilled Polypropylene
555…Polyvinyl Chloride
570…Rulon II
580…Ryton
590…Valox
591…Nylatron G-S
592…Nylatron NSB
600…Virgin PTFE
601…Virgin PTFE (Bronze and moly filled)
602…Filled PTFE
603…Blue Gylon
604…Virgin PTFE
606…Virgin PTFE
610... PTFE Encapsulated Silicon
611…PTFE Encapsulated Viton
Delrin and Hytrel are registered tradenames of
E.I. DuPont.
Gylon is a registered tradename of Garlock. Inc.
Nylatron is a registered tradename of Polymer Corp.
Rulon II is a registered tradename of
Dixion Industries Corporation.
Ryton is a registered tradename of
Phillips Chemical Company.
Valox is a registered tradename of
General Electric Company.
SANDPIPER, PortaPump, Tranquilizer,
SludgeMaster and Warren Rupp are
registered tradenames of IDEX AODD, Inc.
45 866-074-330 Fitting 2
46 866-075-330 Fitting 2
47 900-001-330 Washer, Lock 2
48 900-004-330 Washer, Lock 6
49 900-006-330 Washer, Lock (CI Models) 18
(SS Models) 20
50 132-022-360 Bumper (goes to head of item 38) 2
51 901-005-330 Washer, Flat (GH2 only) 6
52 050-005-360 Ball, Check Valve (CI Only) 2
050-005-363 Ball, Check Valve (CI Only) 2
050-010-600 Ball, Check Valve (CI Only) 2
050-017-360W Ball, Check Valve (SS Only) 2
050-018-600 Ball, Check Valve (SS Only) 2
53 115-064-080 Bracket, Mounting (GH2, CI Only) 1
115-072-080 Bracket, Mounting (GH2, SS Only) 1
54 196-029-015 Chamber, Inner 1
55 196-053-010 Chamber, Outer 1
196-047-110 Chamber, Outer 1
56 286-036-360 Diaphragm 1
286-036-363 Diaphragm 1
57 312-046-020 90° Street Elbow (CI Only) 1
312-046-110 90° Street Elbow (SS Only) 1
58 334-038-010 Flange, Suction 1
334-044-110 Flange, Suction 1
59 334-039-010 Flange, Discharge 1
334-043-110 Flange, Discharge 1
60 618-003-330 Plug, Pipe (CI Only) 1
618-003-110 Plug Pipe (SS Only) 1
61 722-040-110 Seat Check Valve (SS Only) 2
722-042-080 Seat, Check Valve (CI Only) 2
62 560-079-360 O-Ring (CI Only) 4
560-079-611 O-Ring (CI Only) 4
560-106-360 O-Ring (SS Only) 4
560-106-363 O-Ring (SS Only) 4
720-060-608 Seal (SS Only) 4
69 618-003-110 Plug, Pipe 1
70 326-006-080 Foot (SS Only) 1
71 866-076-330 Fitting 1
For models with PTFE overlay pumping diaphragm:
63
612-097-110 Plate, Diaphragm (Outer) 1
612-039-010 Plate, Diaphragm (Outer) 1
64 286-020-604 Diaphragm 1
65 286-005-360 Diaphragm 1
66 612-047-330 Plate, Diaphragm (Inner) 1
67 900-007-330 Washer, Lock 1
68 545-009-330 Nut, Hex 1
Not Shown:
545-008-330 Nut, Hex (SS Only) 4
900-003-330 Washer, Lock (SS Only) 4
