Model ET2-M Type 1 Page 8 et2dl2sm-0614
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 070-006-170 Bearing, Sleeve 2
2 114-002-156 Bracket, Intermediate 1
3 720-004-360 Seal, U-Cup 2
4 135-008-000 Bushing, Threaded, with o-ring 2
5 620-004-114 Plunger, Actuator 2
6 095-073-000 Assembly, Pilot Valve* 1
6-A 095-070-558 Valve Body 1
6-B 755-025-000 Sleeve (without o-ring) 1
6-C 560-033-360 O-Ring (Sleeve) 4
6-D 775-026-000 Spool (without o-ring) 1
6-E 560-023-360 O-Ring (Spool) 2
6-F 675-037-080 Retaining Ring 1
7 360-041-425 Gasket, Valve Body 1
8 560-001-360 O-Ring 2
9 095-043-156 Body, Valve 1
10 132-014-358 Bumper, Valve Spool 2
11 165-066-010 Cap, End 2
12 360-048-425 Gasket, Valve Body 1
13 360-010-425 Gasket, End Cap 2
14 560-020-360 O-Ring 6
15 031-066-000 Sleeve & Spool Set 1
16 170-032-330 Capscrew, Hex Head 8
17 170-045-330 Capscrew, Hex Head 4
18 132-002-360 Bumper, Diaphragm 2
19 196-001-157 Chamber, Inner 2
20 286-007-365 Diaphragm 2
286-007-363 Diaphragm 2
286-007-360 Diaphragm 2
286-007-366 Diaphragm 2
286-007-364 Diaphragm 2
286-007-356 Diaphragm 2
21 560-022-360 O-Ring 2
22 685-007-120 Rod, Diaphragm 1
23 170-100-330 Capscrew, Hex Head 16
24 170-024-330 Capscrew, Hex Head 8
25 618-003-330 Plug, Pipe 4
26 900-006-330 Washer, Lock 8
27 612-047-330 Plate, Diaphragm 2
28 612-039-157 Plate, Outer 2
29 807-026-330 Stud 2
30 901-022-330 Flat Washer 16
31 545-007-330 Nut, Hex 16
32 722-040-365 Seat, Valve 4
722-040-363 Seat, Valve 4
722-040-360 Seat, Valve 4
722-040-364 Seat, Valve 4
722-040-600 Seat, Valve 4
722-040-110 Seat, Valve 4
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most War-
ren Rupp distributors. The pump owner
may prefer to maintain a limited inventory
of these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
CONTAINMENT DUTY Type 1
ET2 - M
SERVICE AND OPERATING MANUAL
Original Instructions
