et1dl3sm-rev0614 Page 8
1 095-051-558 Body, Spool Valve 1
2 031-083-000 Sleeve & Spool Set w/Pins 1
3 560-058-360 O-Ring 8
4 165-078-147 Cap, End 2
5 675-043-115 Ring, Retaining 2
6 165-042-157 Cap, Valve Body 1
165-042-558 Cap, Valve Body *1
7 360-056-379 Gasket 1
8 360-057-360 Gasket 1
9 360-058-360 Gasket 1
10 095-074-001 Assembly, Pilot Valve** 1
10-A 095-071-557 Valve Body 1
10-B 755-025-000 Sleeve (without O-Ring) 1
10-C 560-033-360 O-Ring (Sleeve) 4
10-D 775-014-000 Spool (without O-Ring) 1
10-E 560-023-360 O-Ring (Spool) 4
10-F 675-037-080 Retaining Ring 1
11 170-063-115 Capscrew, Hex Head 1
12 901-035-115 Washer, Flat 1
13 542-001-115 Nut, Square 1
14 170-033-115 Capscrew, Hex Head 4
15 901-005-115 Washer, Flat 4
16 170-043-115 Capscrew, Hex Head 6
170-018-115* Capscrew, Hex Head *6
17 114-007-157 Bracket, Intermediate 1
114-012-010* Bracket, Intermediate *1
18 196-042-157 Chamber, Inner 1
196-090-010* Chamber, Inner *1
19 196-043-157 Chamber, Inner 1
196-084-010* Chamber, Inner *1
20 560-040-360 O-Ring 2
21 560-001-360 O-Ring 2
22 135-034-506 Bushing 2
23 675-042-115 Ring, Retainer 2
24 620-007-114 Plunger, Actuator 2
25 132-022-360 Bumper 2
26 070-012-170 Bearing, Sleeve 2
27 720-010-375 Seal, U-Cup 2
28 196-057-110 Chamber, Outer 2
29 901-012-180 Washer, Sealing 2
30 115-078-115 Bracket, Mounting 1
31 675-040-360 Ring, Sealing 2
32 685-039-120 Rod, Diaphragm 1
33 132-019-360 Bumper 2
34 612-101-110 Plate, Outer Diaphragm 2
35 612-022-330 Plate, Inner Diaphragm 2
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
Repair Parts shown in bold face (dark-
er) type are more likely to need replace-
ment after extended periods of normal
use. The pump owner may prefer to
maintain a limited inventory of these
parts in his own stock to reduce repair
downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
CONTAINMENT DUTY Type 3
SERVICE AND OPERATING MANUAL
Original Instructions
ET Model Pumps
