hdf3mdl2sm-rev1110 Model HDF3-M & HDF4-M Page 2
Materials
Operating Temperatures
For specific applications, always consult “Chemical Resistance Chart" Technical Bulletin
Nitrile General purpose, oil-resistant. Shows good solvent, oil, water and hydraulic fluid resistance. Should
not be used with highly polar solvents like acetone and MEK, ozone, chlorinated hydrocarbons and nitro
hydrocarbons.
NEOPRENE All purpose. Resistant to vegetable oils. Generally not affected by moderate chemicals, fats,
greases and many oils and solvents. Generally attacked by strong oxidizing acids, ketones, esters, nitro
hydrocarbons and chlorinated aromatic hydrocarbons.
HYTREL ® Good on acids, bases, amines and glycols at room temperature.
Urethane Shows good resistance to abrasives. Has poor resistance to most solvents and oils.
Maximum Minimum
‡ CF-8M Stainless Steel equal to or exceeding ASTM specification A743 for corrosion resistant iron chro-
mium, iron chromium nickel, and nickel based alloy castings for general applications. Commonly referred
to as 316 Stainless Steel in the pump industry.
190°F -10°F
88°C -23°C
200°F -10°F
93°C -23°C
220°F -20°F
104°C -29°C
150°F +32°F
66°C 0°C
Maximum and Minimum Temperatures are the limits for which
these materials can be operated. Temperatures coupled with
pressure affect the longevity of diaphragm pump components.
Maximum life should not be expected at the extreme limits of
the temperature ranges.
Meanings of
Abbreviations:
A = Compressed Fibre DI = Ductile Iron PS = Plated Steel
B = Nitrile H = Hytrel ® SS = Stainless Steel
CI = Cast Iron N = Neoprene U = Urethane
Most types available in dual port design. See price book or consult factory for details.
Hytrel is a registered tradename of E.I. du Pont. Santoprene is a registered tradename of Exxon Mobil Corp.
Explanation of Pump Nomenclature, HDF3-M & HDF4-M
II 2GD T5
II 1 G c T5
II 3/1 G c T5
II 1 D c T100oC
I M1 c
I M2 c
Models equipped with Cast Iron wetted parts, and Cast
Iron midsection parts. See page 18 for ATEX Explanation
of EC-Type Certificate.
MATERIALS OF CONSTRUCTION
HDF3-M
Type
Manifold
Elbow
Outer
Chamber
Inner
Chamber
Outer
Diaphragm
Plates
Inner
Diaphragm
Plate
Intermedi-
ate Housing
Diaphragm
Rod
Valve
Seat
Hardware Diaphragm Flap
Valve
Material
Seat
Gasket
Sealing
Rings
Shippping
Wt. (lbs)
DA2II CI CI DI CI PS CI 416SS SS PS N U A B 245
DN2II CI CI DI CI PS CI 416SS SS PS N N A B 363
DB2II CI CI DI CI PS CI 416SS SS PS B B A B 363
DK2II CI CI DI CI PS CI 416SS SS PS N H A B 363
HDF4-M
Type 2
DN2II CI CI DI CI PS CI 416SS SS PS N N A B 390
DB2II CI CI DI CI PS CI 416SS SS PS B B A B 390
DA2II CI CI DI CI PS CI 416SS SS PS N U A B 390
To order a pump or replacement parts, first enter the Model Number HDF3-M, or HDF4-M, followed by the Type Designation listed below in the far left column.
