8
Assembly
3. Slide the drill press head over the column.
(Fig.03)
4. Center the drill press head over the table and
base. Tighten the drill press head into position
by locking the two hex screws on the side of
the casting. (A-Fig.04)
Fig.03
Fig.04
5. Next, slide the 1/2” chuck (A-Fig.05) over the
pre-installed spindle (B-Fig.05). Open the
chuck jaws fully and tap into place using a
rubber mallet or a hammer and block of wood.
Fig.05
A
A
B
