Rhino Shelter VENTILATION KIT User Manual
Rhino shelter vent kit assembly, Bolts & washers heavy duty double-sided tape

STEP 1: Locate Desired Position For Vent.
STEP 2: With Marker, Lightly Mark The Perimeter Of The Interior Section Of The Vent That Is Touching The Fabric.
STEP 3: Set Vent Aside. Locate New Marks And Carefully Cut Out Marked Area. Cut-Out Area Should Be Equal To The Area Of The Vent
Minus The Frame.
STEP 4: Attach As Indicated Above Using One Of The Methods Described (please note that mounting hardware is NOT included due to the
variety of mounting methods available).
Fabric
Fabric
RHINO SHELTER VENT KIT ASSEMBLY
BOLTS & WASHERS
HEAVY DUTY
DOUBLE-SIDED TAPE
Typical Vent Locations:
- Directly Above Door Front and Back
- Along Sidewall
- Along the Eve of the Roof (house style units only)
An Example of the Vent Kit Being Used Directly
Above Roll Up Door.
Frame
Vent Interior
For All Questions or Shortages Please Call MDM Products Directly
Customer Service 800-447-7079 or 203-877-7070
