©2010 Johnson Level & Tool - Rev. 1 9
Fine Calibration
1. Remove plastic screws on front and left of the laser.
2. With the unit on its base on a flat platform, turn the laser on.
3. Return the laser back to its original starting point when
self-checking the laser.
4. Use a 2mm allen wrench to turn the front adjusting screw to
position the laser beam forward and backward.
5. Use the side adjusting screw to position the laser beam left and
right.
6. Move the top beam to the intersection of the 4 dots shown in
Fig. A of self-check calibration.
7. Perform another self-check calibration as described previously to
make sure the laser is calibrated.
8. If the laser is still beyond its accuracy specification, recalibrate the
laser again.
9. If laser is still out of calibration, contact Johnson Level & Tool for
service.
10. Return the plastic screws being careful to not over tighten.
