©2011 Johnson Level & Tool

7

6. Operating Instructions

IMPORTANT: It is the responsibility of the user to verify the
calibration of the instrument before each use.

Notes:
• Always check to make sure that the laser is in the off position

(when power indicator lamp is not lit) before removing
and replacing batteries.

• Both Ni-MH (40-6529 & 40-6544) and “C” alkaline batteries (included

in 40-6526 only) can be used in the unit’s battery compartment.

5. Location of Part/Components

Rotating Head

5/8” thread hole on side

5/8” thread hole on bottom

Screw for battery cover

Output Window

Remote Receiving

Point in horizontal
direction

Handle

4411H-English_Manuals 3/11/11 1:13 PM Page 7
