10 ©2012 Johnson Level & Tool - Rev. 2
3. The horizontal calibration is complete.
Figure 9 Figure 10
7. Technical Specifications
Accuracy ±0.1º for 0º and 90º,
and ±0.2º for 1º and 89º
Working Range 4 x 90º
Power Supply 3 “AAA” alkaline batteries
Battery Life Approx. battery life 100 hours
continuous use
Dimensions 6.45" x 2.3" x 1.25"
(164 x 60 x 32mm)
Weight 0.66 lbs. (0.3 Kg)
Working Temperature 14°F to 113°F (-10°C to +45°C)
5670H-English_Manuals 5/2/12 9:01 AM Page 10
