12 ©2009 Johnson Level & Tool
6. Technical Specifications
Telescope Erect
Magnification 22X
Leveling accuracy ± 3/16"/100 ft. (±5mm/30m)
Working range Up to 200’ (60m)
Minimum focus 4’ (1.2m)
Clear objective aperture 22mm
Field of view ± 2’/100 ft. (±0.6m/30m)
Number of lenses 5
Level vial 4’ per 2mm
Horizontal circle:
Graduation diameter 110mm
Graduations 1º
Number Each 10º, 0-90-0º
Vernier Double direct to 15 min.
Weight 2.204 lbs (1Kg)
Center screw thread 5/8” - 11
