6
D. Controls
Main Unit (Refer to Figure 1)
AVD400A DVDPLAYER
DOLBY
1 10
9
8
7 6 5 4 3
2
1
C C F
DOLBY
11
12 13 14 15 16 17 18
1. Power Button
2. Play/Pause Button
3. Mode Button
4. Remote Control Sensor
5. Video Input
6. Left Audio Input
7. Right Audio Input
8. Next Button
9. Previous Button
10. Eject Button
11. IR Input
12. Digital Audio Output
13. Audio R Output Jack
14. Audio L Output Jack
15. Video Output Jack
16. S-Video Output Jack
17. External Remote Eye Input
18. DC In 12V Power Supply Connector
Figure 1
