ASUS SCB-1608-D User’s Manual 27
Technical Information
Environmental Specifications
Temperature Operation: 5°C < to < 40°C
Storage: - 20°C to < 60°C
Humidity Operation: 5% to 80% non-condensing
Storage: 5% to 90% non-condensing
Vibration Operation: 0.25G peak at 5 ~ 500 Hz
Storage: 1.5G peak at 10 ~ 500 Hz
Impact Non-operation: 1 oct/min – no damage
Less than 50G –
(at 11ms/half sine wave,
3 shock/each side)
Packaged: 1 oct/min – no damage
91 cm high –
(1 corner, 3 edges, 6 surfaces)
Acoustic Access mode: 41.5 dB TYP
Read mode: 44.5 dB TYP
( Microphone located 50cm in front of the drive, 120 cm above the drive at 30 o angle. )
Reliability MTBF: 60,000 power on hours
ODC (Read): 20% of power on time
ODC (Write): 1% of power on time
Mean Time To Repair (MTTR) 30 minutes
Electrical and Audio Specifications
Power Source Input Linear Voltage 110/240 V AC
Input Linear Frequency 50/60 Hz
Input Linear Current 1.0 A
I/O Terminal USB terminal USB B type ( High Speed )
IEEE1394 terminal IEEE1394
Audio No. of channels 2 (stereo)
Sampling frequency 44.1 kHz
Quantization
16 bits
Distortion 0.2% max. (at 1 kHz)
S/N ratio 70 dB
Output: Headphone 0.7 V rms (typical)
