37
10.1: Mandatory Disclosures
This instruction manual addresses foreseeable hazards, uses and
applications. If you have questions about your application that are not
addressed in this document, contact FallTech for additional guidance.
It is the responsibility of the employer/issuer of this equipment to
ensure that it is used in a manner consistent with these instructions.
Failure to do so could result in serious injury or death.
For further reading and additional information, see Section 10.4 for a
listing of relevant standards with which you should be familiar.
10.2: Performance Specifications
Full specification sheets for each Full Body Harness are available
through FallTech. All FallTech FBH’s meet or exceed the minimum
requirements of both OSHA under Title 29 CFR, as well as those
outlined in ANSI Z359.1-2007, ANSI Z359.12-2009 and ANSI A10.32-
2004. Specification data is also shown on the labels of your FallTech
FBH.
Below are the minimum specifications for your FallTech FBH:
FBH Component Min. Tensile Strength
D-rings 5,000 lbs./ 2,273 kg / 22.2 kN
Buckles 3,375 lbs./ 1,534 kg / 15 kN
Adjusters 3,375 lbs./ 1,534 kg / 15 kN
Webbing 5,000 lbs./ 2,273 kg / 22.2 kN
10.3: Labels and Markings
The labels shown below must be present on the product and must be
legible. If they are not, remove the product from service.
Product Labels – Located on Torso Strap
38
Load- Indicating Safety Tabs – Located on Back Torso Straps
