Can be used to connect up 63 external devices, also supports isochronous data --
delivering data at a guaranteed rate. This makes it ideal for devices that need to
transfer high levels of data in real-time, such as video devices. Also supports both
Plug-and-Play and hot plugging, and also provides power to peripheral devices.
PCMCIA Socket Cover 3 3 . .
4 4 . .
5 5 . .
Open this cover to access the PCMCIA socket. The computer’s PCMCIA socket lets
you extend the capabilities of your computer by inserting PC cards.
PCMCIA Socket Button
The computer has one PCMCIA type II socket
The LAN Port
This jack provides a standard RJ-45 connection for integration with an existing
network or a high-speed (DSL or cable) connection via a network cable.
When using a LAN, please use an EMI Shielding Cable to minimize
an inteference when transmitting.
6 6 . . The Modem Port
This jack is an internal 56K voice/fax/data modem. You will connect your computer
to your phone line through this port.
Always disconnect all telephone lines from the wall outlet before
servicing or disassembling this equipment. To reduce the risk of fire
use only No. 26 AWG or larger telecommunication line cord.
7 7 . . Microphone Jack
Allows you to receive monophonic input from an external microphone. Use of an
external microphone will disable the built-in microphone.
24
