■ chapter 4 upgrading your computer

4-14

angle of approximately 30 degrees into the empty memory

socket. Then press it firmly so that the contact edge is driven

into the receiving socket.

Pivot the DIMM until the latches on both sides of the

socket snap into place.

Note:

Notice the notch on the DIMM. The notches should fit nicely with the

socket.

Put the Metal Cover back. Put the keyboard back to its

original position. Make sure the edge of the keyboard now

resides under the spring-loaded latches.
