■ chapter 1 getting to know the basics
1-9
4. Modem Port / Port or Antenna Connector for DVB-T Digital
Broadcast TV (Optional Device)
This is where you plug the phone jack (RJ-11) for fax/modem
functions.
For certain configuration, your computer may be installed with
the optional DVB-T module. In stead of the Modem Port, this is
an antenna connector. If your system has the DVB-T option,
you should plug the antenna into the connector. Please see
DVB-T Digital Video Broadcast TV
section later in this chapter
for more information. Please see Chapter 4 if you are installing
the DVB-T module by yourself.
5. Kensington Lock Key Hole
A Kensington-type security lock latches to this keyhole for
anti-theft purpose.
6. USB2.0
Port (x3)
The Universal Serial Bus (USB2.0-compliant) port allows you to
connect a wide variety of devices to your computer at a rate of
up to 480 Mbps. This port conforms to the latest USB2.0
plug-and-play standards.
7. Firewire / IEEE1394 / 1394a Port
This is a high-speed serial data port. You may connect any
Fire-wire-ready device to this port.
8. 4-in-1 Card Reader
The 4-in-1 Card Reader supports SD Card, MS Card, MMC
Card, and MS-Pro Card.
9. ExpressCard Slot
The slot is where Express Card (Type I, 34mm) is inserted.
ExpressCard integrates both the PCI-Express bus technology
and USB2.0 interface.
Press the card into the slot to insert. Press the card again to
eject.
10. Stereo Headphone / SPDIF-out Jack
