1. GENERAL
1.1 Applications
SC20-25
For faster circulation of water in closed -
circuit domestic (individual) central heating
and air-conditioning systems.
SB25-20, SB30-25, SS30-25
For faster circulation of hot water in:
- Secondary hot water distribution loops.
- Industrial water loops (air conditioning,
cooling, tank circulating).
1.2 Specifications
• Temperature range:
-10
o
to +110
o
C
• Ambient temperature: up to +40
o
C
• Max. service pressure: 10 bar
• Min. suction pressure: 1.5m (0.15 bar)
(m w.g.*)
at +82
o
C;
3m (0.3 bar)
at +95
o
C;
10m (1 bar) at
+100
o
C
• Antifreeze
(water + glycol):
up to 50%
(with the exclusion of all other liquids
without first obtaining the written
approval from Davey Products Pty Ltd)
• Hardness of water (TH): max. 350ppm
• Recommended
flow velocity:
between 0.5
and 1m/s max
NOTE: This pump is not approved nor
intended for use in swimming
pools, spa pools or spa baths.
2. SAFETY
Read this data sheet carefully before
installing and starting up. Pay special
attention to the points concerning the
safety of the equipment for the end user.
2.1 Symbols used in the manual
Warning
Instructions concerning electricity
Calls attention to a potential
risk that might affect safety.
3.
TRANSPORT AND STORAGE
When taking delivery of the equipment,
check that it has not been damaged in
transit.
If the equipment delivered is to be
installed at a later time, store it in a
dry place and protect it from impact
and outside influences (moisture,
frost, etc).
4.
PRODUCTS AND ACCESSORIES
4.1 The Pump
With threaded ports according to model.
The motor has a wet rotor and the
bearings are self lubricating.
Three-speed with manual selection by
selector switch.
• Compliance:
TF10
• Insulation class:
F (155
o
C)
• Protection:
IP42
(only with terminal box at 6, clock
position on SS30-25).
4.2 Accessories
Supplied:
Unions with gaskets
Recommended: Non return valves
Isolating valves
5. INSTALLATION
5.1 Assembly (see FIG. 1&2)
- Make sure that the circulator is
accessible.
- Assemble directly on a pipe, preferably
vertical, and if possible on the boiler
return circuit; never at the low point (to
protect against deposits).
- The motor shaft axis must always be
horizontal.
- The arrow on the pump casing indicates
the direction of water flow (see FIG. 3).
- Install isolating valves on both sides of
the circulator to facilitate removal for
servicing.
If the circulator must
be insulated, we advise
against obstructing the
evacuation notches in the
motor flange (see FIG. 3).
