FOR INFORMATION TEL: 514.337.4415 FAX: 514.337.4029
SAFETY INSTRUCTIONS:
This fine pump that you have just purchased is designed from the latest in material and
workmanship. Before installation and operation, we recommend the following procedures:
Check with your local electrical and plumbing codes to ensure you comply with
the regulations. These codes have been designed with your safety in mind.
Be sure you comply with them.
We recommend that a separate circuit be lead from the home electrical
distribution panel properly protected with a fuse or a circuit breaker. We also
recommend that a ground fault circuit ‘GFCI’ be used. Consult a licensed
electrician for all wiring.
The ground terminal on the three prong plugs should never be removed.
They are supplied and designed for your protection.
Never make adjustments to any electrical appliance or product with the power
connected. Do not only unscrew the fuse or trip the breaker, remove the power
plug from the receptacle.
Assuming that you have a sewage tank located in your basement floor... The
minimum size of your sewage tank MUST be 18” in diameter and no less than
30” deep. When the tank is ready, proceed to next step.
A
B
C
D
Material required for sewage pump application
Desired length of ABS/DWV 2” pipe, to link up from pump discharge to waste or drain
existing pipe.
Required quantities of 2” ABS/DWV elbow(s) and/or other fitting(s) to run the
discharge line.
1 only 2” ABS/DWV male adaptor to 2” slip, to connect the discharge pipe to the pump.
Desired length of ABS/DWV 3” pipe and required quantities of 3” ABS/DWV elbow(s).
and/or other fitting(s) to run the vent line.
1 only 2” union check valve # 450457.
1 only 18” X 30” minimum size sewage basin like # 400420.
Teflon tape and ABS cement.
2
Tools
Screwdrivers, hacksaw to cut pipe, knife to assist in pipe cutting, round file to smooth pipe
ends, pipe wrench, adjustable wrench, 1/4” drill bit and drill. Ensure that you have a gas tight
cover for your sewage basin and 3” ABS/DWV vent piping.
NOTICE
This unit is not designed for applications
involving salt water or brine .
Use with salt water or brine will void
warranty.
E
