Please Note:
For “stock” vehicles and front end lifts up to 4” we recommend the bent bar be in-
stalled with the clevis pressed in from the bottom.
For vehicles with 4” and more the straight bar can be mounted with the clevis
pressed in on the top.
Moreover, with the presence of an aftermarket track bar relocation bracket and or
drop pitman arm, it is recommended the new track bar and clevis be installed so that
the track bar is positioned as parallel to the drag link as possible.
www.ReadyLIFT.com
Phone (702)410-2300
Installation Instructions (77-2000 & 77-2001)
Remove ball joint from axle. Inspect and clean surface and edges if necessary.
Position clevis in place w/socket head bolt, washer and nut Mark clevis to axle and insert track bar to ensure proper fit.
Use assembled track bar as a guide to ensure proper position Use press tool to draw clevis into position
Large washer
Clevis
Check clearance
during installation
Important!
Online video install available
