Display, Touch screen (optional) – Nematron ePC-Plus Series with T7500 CPU User Manual
Page 6

6
DISPLAY
ePC1550
ePC1750
ePC1950
Display Diagonal
15.0” (381.0mm)
17.0” (431.8mm)
19.0” (482.6mm)
Display Size (Active
Area H x V)
11.97” x 8.98”
(304.0mm x 228.1mm)
13.30” x 10.64”
(337.8mm x 270.3mm)
14.82” x 11.85”
(376.4mm x 301.0mm)
Native Resolution
XGA, 1024 x 768
SXGA, 1280 x 1024
SXGA, 1280 x 1024
Displayable Colors
16M
16M
16M
Brightness, Typical
300 Nit
380 Nit
300 Nit
Contrast Ratio, Typical
800:1
1000:1
2000:1
Horizon/Vertical
View
Angle, CR>5, Typical
150
°/145°
176
°/170°
178
°/178°
Backlight Life, Typical
50,000 hrs
50,000 hrs
50,000 hrs
TOUCH SCREEN (Optional)
Touch Screen Technology
5- Wire Analog Resistive
Interface
Internally via USB
Resolution
4096 x 4096
Positional Accuracy (Maximum Error)
0.18” (0.19” ePC1900)
4.57mm (4.83mm ePC1900)
Positional Accuracy (Standard Deviation of Error)
< 0.08” (< 2.0 mm)
Expected Life
>35,000,000 Activations
