6 Technical Specifications
Maximum Output 30Hz - 20kHz
Stereo 25W @ 8Ω per channel
35W @ 4Ω per channel
Frequency Response (+0, -3 dB) 30Hz-20kHz
Bandwidth +/- 3.0dB 30Hz-30kHz
THD+N <0.1%
Signal to noise ratio >100dB
External Mute 5-12VDC
Slew Rate 30V/ms
Input Sensitivity 0.5V (-3 dBV)
Standard Voltage Gain 28X (26.5dB)
Input Impedance (Balance/Unbalanced) 20k Ohms/10k Ohms
Sleep, Idle Current Draw, 1/8 Draw 0.005/0.01/0.15 Amps
Class D
Input Connectors Euro Block
Output Connectors Euro Block
Power Supply External In-Line 48DVC
Cooling Convection-Cooling
Controls Level
LED Indicators Power, Signal Present &
Clip
Construction Aluminum Chassis
Dimensions
Height 1.25in (3.2cm)
Width 4.35in (11.1cm)
Depth 3.2in (8.1cm)
Weight 0.37bs (0.16kg)
Stewart Audio reserves the rate to change features and specifications without notice.
