Renkus-Heinz IC32-R-II - Manual (Page 75)

75
Users Manual IC-R-II
6 7/8" 17.5 cm
65 3/4" 167 cm
6 1/8"
15.5 cm
74 3/4" 190 cm
6 1/8
"
15.6 cm
65 13/16
"
167.2 cm 65 13/16
"
167.2 cm
149" 378 cm
6 1/8" 15.5 cm
6 7/8" 17.5 cm
6 1/8" 15.6 cm
17.5 cm
6 7/8"
6 1/8"
15.5 cm
37 5/8" 96 cm
31 7/8" 81 cm
6 1/8" 15.6 cm
65 3/
4
"
167 cm
111
7/8”
284 cm
28 5/16" 71.8 cm
6 1/8" 15.5 cm
6 7/8" 17.5 cm
6 1/8" 15.6 cm
Dimensional Information
IC32-R-II & IC32/16-R-II
IC24-R-II
IC16-R-II & IC16/8-R-II
IC8-R-II
