CONTROLS & CONNECTIONS
23
The
Return / Line In
connector of the VXP is provided for use in
conjunction with audio process devices such as reverbs/delays and as a
Line In for recording media such as tape machines, hard disc recorders, or
DAT’s.
TIP
High
(+)
RING
Low
(-)
SLEEVE
GND
Cable Wiring Diagram for Balanced Send / Return Jacks
The
Send Jack on the back panel of the VXP routes the signal being
processed by the unit to an outboard device such as a reverb or delay or to
recording media.
2 . 7 P O W E R S U P P L Y
The
Power Jack on your VXP accepts a standard IEC cord like those
found on most computers and professional recorders.
Before powering on your VXP for the first time, be sure to check the
position of the power selector. Make certain that the power voltage level
selected for operation of the unit matches that of the country where the unit
will be used. (USA = 115V)
