RTI Technologies, Inc.
Page 9
0 F R12 R134a
30 42 40
32 44 42
34 46 44
36 48 46
38 50 49
40 52 51
42 54 54
44 57 56
46 59 59
48 61 61
50 64 64
52 66 67
54 69 70
56 72 72
58 74 76
60 77 78
62 80 82
64 83 85
66 85 88
68 88 92
70 92 95
72 95 97
74 98 104
76 102 107
78 105 110
80 108 114
82 112 118
84 115 123
86 118 127
88 123 130
90 127 135
92 130 140
94 135 145
96 138 148
98 143 153
100 147 157
102 150 163
104 155 167
106 160 173
108 165 180
110 168 185
112 173 190
114 178 195
116 183 200
118 188 207
120 193 213
Purge Chart
OIL DRAIN & AIR PURGE
Oil and Non-condensable Gas (Air) are separated from
the recovered refrigerant and MUST be removed
following EACH recycling procedure as follows:
1. MOMENTARILY press the top of the Purge
Switch and hold until the pressure reading on the
Pressure Gauge above this button drops one small
graduation mark (approximately 10 PSIG).
2. SLOWLY open the Oil Drain Valve (on lower right
side of TC670E) to vent Non-condensable Gas and
drain any oil which may have been removed from
the A/C System. A plastic cup is provided to collect
and measure the oil.
Unless the A/C System had previously been
overfilled, the TC670E will typically not remove
more than a tablespoon of oil, making replenishment
unnecessary.
Leave the Oil Drain Valve open.
3. Determine the room temperature.
4. Locate the pressure (PSIG) corresponding to this
room temperature (
0 F) in the chart on the top of the
TC670E. This chart is reproduced at the right.
If the pressure indicated on the gauge is greater than
that determined from the chart...
SLOWLY press and hold the Purge Switch until
the gauge pressure approximately equals that
shown in the chart. Any Non-condensable Gas
will be vented through the Oil Drain Valve.
5. Close the Oil Drain Valve.
6. Press the Purge Switch and hold for approximately
5 seconds. This permits any residual Non-
condensable Gas to be recirculated for reprocessing
during the next recycle procedure.
