ABOUT YOUR SWITCHER 2
The MX2406RM is a 6-in 1-out relay switcher
designed to allow the non-simultaneous connection
of up to six computer video sources to a single
monitor or projector. The MX2406RM is
controllable using its built-in front panel, through
RS-232, or through contact closures. Contact
closure control requires the use of an optional
adapter, part # RC5204CC.
The MX2406RM uses relays internally and
therefore may be used to switch other signal types
as well, including RGBHV, RGBS, RGsB,
Component Video (Y, R-Y, B-Y), S-Video (Y/C),
Composite Video, Audio, and even RS-232,
assuming the appropriate adapter cable is used.
Since the MX2406RM uses relays internally, it can
also be used bi-directionally – a signal can be
routed “backwards” through the switcher to allow a
single source to be connected to as many as six
displays.
The MX2406RM offers a 9-pin control port, which
provides a means of interconnection for RS-232
and contact closure control as well as other special
features. For instance, when multiple MX2406RM
units are looped together to create a larger
switcher, two pins on the 9-pin control ports can be
connected to make the switcher respond as a
single unit. Using a similar method, multiple
MX2406RM units can be made to operate in a
Master-Slave mode, with all units responding to a
single button selection.
Using optional hardware, a single MX2406RM can
be rack-mounted by itself or two units can be rack-
mounted side-by-side.
TECHNICAL SPECIFICATIONS 3
FEATURES/
DESCRIPTION
MX2406RM
GENERAL
Inputs
6
VGA Input Connector Six 15-pin HD Female
Outputs 1
VGA Output Connectors 15-pin HD Female
Compatibility VGA/SVGA/XGA/UXGA/,
RGBHV, RGBS, RGsB,
Component Video (Y, R-Y,
B-Y), S-Video (Y/C),
Composite Video,
Table 1. MX2406RM General
MECHANICAL MX2406RM
Material 0.1” Al
Finish Gray
Top Panel Lexan
Height (inches) 3.38in (86mm)
Width (inches) 8.50in (216mm)
Depth (inches) 4.38in (111mm)
Weight (pounds) 3.0lbs (1.36kg)
Ship Weight (pounds) 4.0lbs (1.82kg)
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
MTBF (calculations) 40,000 hrs
Table 2. MX2406RM Mechanical
ELECTRICAL MX2406RM
Input Video Signal
Analog Signal
+/-10V p-p max
Impedance 75 Ohms
Input Sync Signal
Composite Sync
TTL(+/-),Analog 0.3-1.0V
Sync on Green -0.3V
Impedance pass-through
Output Video Signals
Analog Signal
+/-10V p-p max
Fall/Rise Time (ns) 1.9
Impedance 75 Ohms (pass-through)
Output Sync Signal
Composite Sync
TTL(+/-), Analog 0.3-1.0V
(not buffered)
Sync on Green -0.3V
Impedance pass-through
Frequency Compatibility
Typical Video Bandwidth
400 MHz @ -3 dB
Horizontal 15-200 kHz
Vertical 30-190 Hz
Cross-talk -48dB @ 10 MHz
Coupling DC
Power
External Power Adapter
90-140V/200-240V
Power Consumption 12 watts max.
Table 3. MX2406RM Electrical
