SWITCHERS
11
Input 7 through Input 11 [OUT02]
This will setup each switcher as a different output
number. To control the switchers use following
commands (connect the transmit line from the
control system to the receive line on both
switchers):
[I01O01] Select input number 1
[I02O01] Select input number 2
[I03O01] Select input number 3
[I04O01] Select input number 4
[I05O01] Select input number 5
[I06O01] Select input number 6
[I01O02] Select input number 7
[I02O02] Select input number 8
[I03O02] Select input number 9
[I04O02] Select input number 10
[I05O02] Select input number 11.
ACCESSORIES 8
Model No. Description
TABLE MOUNT HARDWARE
TM1276 Table Mount bracket for 2U ½ Rack-
Wide
RACK MOUNTING ACCESSORIES
DA1298RM Rack mount shelf for two units side by
side
DA1299RM Rack ears for single unit.
CONTROL CABLES
RC5204CC Contact Closure Adapter 6 ft
RC5207CC Master-Slave Control cable
HIGH RESOLUTION VGA CABLE
CB3703MR 3 feet VGA Male to Male
CB3706MR 6 feet VGA Male to Male
CB3715MR 15 feet VGA Male to Male
CB3725MR 25 feet VGA Male to Male
CB3750MR 50 feet VGA Male to Male
CB3775MR 75 feet VGA Male to Male
CB37100MR 100 feet VGA Male to Male
CB37150MR 150 feet VGA Male to Male
HIGH RESOLUTION VGA CABLE
CB3903MR 3 feet VGA Male to Female
CB3906MR 6 feet VGA Male to Female
CB3915MR 15 feet VGA Male to Female
CB3925MR 25 feet VGA Male to Female
CB3950MR 50 feet VGA Male to Female
CB3975MR 75 feet VGA Male to Female
CB39100MR 100 feet VGA Male to Female
CB39150MR 150 feet VGA Male to Female
POWER CABLES
PC5301US Power cable for US
PC5302US Power cable for U.K.
PC5303US Power cable for Australia
PC5304US Power cable for Germany
