2
D9015B
8"
(203.2mm)
5"
(127mm)
5.75"
(146.1mm)
12"
(304.8mm)
5"
(127mm)
15"
(381mm)
D9016B
14.125"
(358.8mm)
7.125"
(181mm)
17.125"
(435mm)
6.75"
(171.45mm)
6"
(152.4mm)
10"
(254mm)
DIMENSIONAL DATA
Figure 2a – 5 Inch Combustion Air Inlet Box Assembly
Figure 2b – 6 Inch Combustion Air Inlet Box Assembly
