ENGLISH
ENGLISH
BIDET INSTALLATION
2
4
1 BEFORE PROCEEDING
WARNING: Read all the instructions completely before proceeding. Price
Pfister recommends calling a qualified plumber if you are uncertain about installing
this product!
This product should be installed in accordance with all local and state plumbing and
building codes. Vitreous china is heavy and fragile. Use extreme care with all
parts!
2 SHUT OFF WATER SUPPLY
Locate water supply inlets and shut off the water supply valves. These are usually found
behind the toilet or near the water meter. If you are replacing an existing toilet, remove
the old toilet from the floor and clean the finished floor surface thoroughly.
3 TOOLS RECOMMENDED
• Silicon sealant • Screwdriver • Adjustable wrench
• Pliers • Measuring Tape • Safety glasses
Your installation may require new supply lines and / or shut-off valves or other
additional tools.
4 BIDET INSTALLATION
Lubricate seals with appropriate rubber seal lubricant. Insert discharge pipe (4A) and
small pipe (4B) into the hubs in the wall.
Apply silicon sealant (5A) to backside of bowl.
Thank you for purchasing this Price Pfister product. All Price Pfister products are carefully engineered, and factory tested to pro-
vide long trouble-free use under normal conditions. This product is easy to install using basic tools and our easy to follow illustrated
instructions. If you have any questions regarding this product, call 1-800-Pfaucet (1-800-732-8238).
Place bowl (6A) onto hanger bolts (6B).
Place the Plastic Washer (7A) and Metal Washer (7B) on the Mounting Bolt (7C).
Secure by tightening the Mounting Nuts on to the Mounting Bolts. Caution: Do not
over tighten! Finish by snapping on Plastic Caps (7D) over bolts and nut as shown.
7
5
6
2
5A
4A
7A
7D
7B
4B
6A
6B
7C
