1-4
Operation Manual
7200
1.2.2 Functions
No. Names Functions
A Operator panel Houses the LEDs and keypad needed to operate
the ATB printer.
B Cover lock Locks the side cover. (Use the key to open the
cover.)
C Inserter Used to insert single coupons (one at a time).
D Output stacker Receives ejected coupons, print-side up. (Has a
capacity of 100 coupons.)
E Feed knobs Used to remove jammed coupons.
F BIN 1, BIN 2, and BIN 3
load knobs
Used to load coupons into the feed rollers for
each bin.
G BIN 1 Used to hold coupons for printing. (BIN 1 has a
capacity of 500 coupons.)
H BIN 2 Used to hold coupons for printing. (BIN 2 has a
capacity of 500 coupons.)
I Thermal head Prints on the coupon.
J Interface connector
(downline)
Used to connect the printer to a downline printer
(reserved).
K Power switch Turns the power on and off.
L Power connector Used to connect the power cable.
M Interface connector (Host) Used to connect the ATB printer to the terminal.
N BIN 3 Used to insert coupons. (BIN 3 has a capacity of
1000 coupons externally.)
O Thermal transfer take-up
reel Holds used ribbon after thermal transfer printing
(type D unit only).
P Thermal transfer supply
reel Supplies ribbon for thermal transfer printing (type
D unit only).
