Acer 4150 Series - Manual (Page 11)

3
Eng
lis
h
Right view
4 Modem jack (RJ-11) Connects to a phone line.
6 Speaker-out/line-out/
headphone jack Connects to audio line-out devices
(e.g., speakers, headphones).
7 Line-in/mic-in jack Accepts inputs from external microphones.
8 Optical drive Internal optical drive; accepts CDs or DVDs
depending on the optical drive type.
9 Optical drive eject
button Ejects the optical drive tray from the drive.
# Icon Item Description
1 Infrared port Interfaces with infrared devices
(e.g., infrared printer and
IR-aware computer).
2 Hard disk bay Houses the computer's hard disk
(secured by a screw).
3 PC Card slot eject
button Ejects the PC Card from the slot.
4 6-in-1 card reader Accepts MS, MS PRO, MMC, SD,
SM, and xD-Picture cards.
Note: Only one card can operate
at any given time.
5 PC Card slot Connects to one Type II CardBus
PC Card.
# Icon Item Description
