SM750 USB3.0 Zero Client
BLOCK DIAGRAM
LynxUSB Plus
Zero Clients
Gaming
Dock Stations
Other Embedded
Graphics Applications
LynxUSB Plus is a USB3.0 zero client reference design kit solution, designed for a client connecting to a
host server computer through the USB3.0 interface. Featuring Silicon Motion SM750 GPU, dual analog
RGB and digital HDMI/DVI display outputs are provided for enhanced display options. With greater
flexibility and security, LynxUSB Plus offers USB ports for various user I/O peripheral supports including
keyboard, mouse, audio, and other devices.
