Allen-Bradley
When using a Bulletin 1494F flange-mount-
ed disconnect switch, order:
1. A disconnect switch
2. A fuse block adapter, if required
3. Line and load connectors, if required
When using a Bulletin 1494D flange-mount-
ed operator for a circuit breaker, order:
1. A circuit breaker
2. A flange-mounted operating mechanism
3. A slide mechanism
When using a Bulletin 1494V disconnect
switch, order:
* 1. A disconnect switch
* 2. An operating handle
* 3. A connecting rod (long)
* 4. A trailer fuse block kit, if required
* 5. A fuse clip kit, if required
6. Line and load connectors, if required
When using a Bulletin 1494V circuit
breaker operating mechanism, order:
1. A circuit breaker
2. A circuit breaker operating mechanism
3. An operating handle
4. A connecting rod (long)
ABB Controls
When using a disconnect switch, order:
1. A flange operated switch (fusible or
non-fusible)
2. A shaft [DSFHS-17 for 18.12”
(460mm) deep or DSFHS-22 for
20.12" (511mm) deep enclosures; in
24.12" (613mm) deep enclosures a
platform must be used with shaft]
3. A handle (DSFHN-HS12)
When using a circuit breaker, order:
1. A circuit breaker (ABB)
* 2. An operating mechanism
* 3. A shaft [FHS-17 for 18.12” (460mm)
deep or FHS-22 for 20.12" (511mm)
deep enclosures; in 24.12" (613mm)
deep enclosures a platform must be
used with shaft]
* 4. Handle mechanism (FHN-HS12)
Eaton Cutler-Hammer
When using a Type C361 disconnect
switch, order:
* 1. A disconnect switch with an
operating mechanism
* 2. An operating handle (C361H1 or
C361H3)
When using a Type C371 circuit breaker
operating mechanism with a C-H circuit
breaker, order:
* 1. A circuit breaker
* 2. An operating mechanism
* 3. An operating handle
When using a Type SM handle mechanism,
order:
1. A circuit breaker
2. A type SM handle mechanism
When using a Flex Shaft ™ handle
mechanism, order:
1. A circuit breaker
2. A complete Flex Shaft
™ handle
mechanism
General Electric
When using a disconnect switch, order:
1. A disconnect switch (Type QMR or
QMW)
2. A fuse clip kit or no-fuse kit
3. A flange handle (STDA1 or STDA2)
4. A variable depth operating mechanism
5. An extended length drive rod
When using a circuit breaker, order:
1. A circuit breaker
2. A flange handle (STDA1 or STDA2)
3. A variable depth operating mechanism
4. An extended length drive rod
When using a circuit breaker with a Spectra
Flex
™ cable operator, order:
1. A circuit breaker
2. A flange-mounted handle mechanism
3. A breaker-mounted mechanism
4. An operating cable
Siemens ITE Max-Flex ™
When using a disconnect switch, order:
1. A basic switch (right-hand)
2. A fuse or no-fuse kit
**3. FHOHS flange-mounted handle
**4. Switch operator
**5. FHOECO48 cable
When using a circuit breaker, order:
1. A circuit breaker
2. Pressure wire connectors
**3. A flange-mounted handle
**4. A circuit breaker operator mechanism
**5. An operating cable [18.12" (460mm)
deep or 20.12" (511mm) deep
enclosures accept 36.00" (914mm)
or 48.00" (1219mm) cables; 24.12"
(613mm) deep enclosures require
a 48.00" (1219mm) cable]
** These items are available from Siemens ITE Max-Flex ™
as a complete mechanism with a 36.00" (914mm)
operating cable only. Order items separately when
using a 48.00" (1219mm) operating cable.
Schneider Square D ®
When using a disconnect switch, order:
1. A disconnect switch with operating
mechanism
2. A universal handle mechanism
3. A long operating rod, if required
When using a circuit breaker, order:
1. A circuit breaker
2. An operating mechanism
3. A universal handle mechanism
4. A long operating rod, if required
When using a Class 9422 Type “T” discon-
nect switch with a cable mechanism, order:
1. A disconnect switch with operating
mechanism (Class 9422 Type T)
2. A handle mechanism (Class 9422
Type A-1)
3. A cable mechanism (Class 9422
CFT_O) 3-, 5-, or 10-foot
When using a circuit breaker with a cable
mechanism, order:
1. A circuit breaker (Schneider Square D ® )
2. A handle mechanism (Class 9422
Type A-1)
3. A cable mechanism (Class 9422
CFT_O) 3-, 5-, or 10-foot
PLEASE NOTE:
1. Various other switch accessories and circuit breaker accessories are available from dis-
connect manufacturers. The above information is subject to change without notice. Please
contact Hubbell-Wiegmann or the disconnect manufacturer if there are further questions.
2. The “Space Occupied” tables (pages F51-F60) are based upon information supplied by
disconnect manufacturers. Hubbell-Wiegmann does not assume responsibility for the
accuracy of these dimensions.
* Items available from disconnect manufacturer as complete kits.
DISCONNECT ORDERING INFORMATION
When ordering wall-mounted disconnects from the various manufacturers, be sure to order
all of the necessary items. Each company has a different system, so care is required. Order
the following items from the disconnect manufacturer.
W A X - S S N 4 , W A X M - S S N 4 & W A C P X - S S N 4 S E R I E S E N C L O S U R E S
N E M A 4 X R I G H T F L A N G E F R E E S TA N D I N G D I S C O N N E C T
