PI Configurator Installation Guide
Version 2.0 April 2005
Page 4
Dispenser Specific Installation
Wayne/Dresser Electronic Dispenser
Note all warnings in System Installation Warnings section.
Installation instructions in this manual refer to the specific DBoxes supplied by dispenser manufacturers,
used in conjunction with the PI Configurator, in a Progressive International product installation. If using
Progressive International’s PI DBox (which replaces both the dispenser manufacturer’s DBox and the PI
Configurator), refer to the PI DBox Installation Guide.
Follow instructions in the installation section of the accompanying product manual before connecting
PI Configurator as follows:
1. Disconnect the Wayne/Dresser console (if applicable) from the distribution box and connect
the Wayne/Dresser style PI Configurator to the Wayne/Dresser DBox and to the PIE product,
using the appropriate cables supplied by PIE. Refer to Diagram: PIE Product to PI
Configurator to Wayne/Dresser Electronic Dispenser following this section.
2. On PI Configurator board, locate jumper H1and select position B. Locate position H2 and
select H (high). Refer to Current Loop PI Configurator Jumper Selection — Wayne.
3. Proceed with programming of system.
