PI Configurator Installation Guide
Version 2.0 April 2005
Page 2
Dispenser Specific Installation
Gilbarco Electronic Dispenser
Note all warnings in System Installation Warnings section.
Installation instructions in this manual refer to the specific DBoxes supplied by dispenser manufacturers,
used in conjunction with the PI Configurator, in a Progressive International product installation. If using
Progressive International’s PI DBox (which replaces both the dispenser manufacturer’s DBox and the PI
Configurator), refer to the PI DBox Installation Guide.
PIE ships current loop configurators as standard for use with Gilbarco DBoxes. Some Gilbarco
DBoxes are configured for RS422 operation. If the RS422 DBox cannot be converted to current loop
operation, you must use an RS422 configurator and cables. Contact your PIE dealer to order.
Follow instructions in the installation section of the accompanying product manual before connecting
PI Configurator as follows:
1. Disconnect the Gilbarco console (if applicable) from the distribution box and connect the
Gilbarco style PI Configurator to the Gilbarco DBox and to the PIE product, using the
appropriate cables supplied by PIE. Refer to Diagram: PIE Product to PI Configurator to
Gilbarco Dispenser following this section.
2. On PI Configurator board, locate jumper H1and select position A. Locate position H2 and
select L (low). Refer to Current Loop PI Configurator Jumper Selection — Gilbarco.
3. Proceed with programming of system.
Note: All Single Product Dispensers (SPDs) must be set for grade 1.
Listing: Gilbarco DBoxes
G ilbarco DBox Part # Description
PA01330000 Old Style with DIN connector
PA0261X000010 Universal Style with 1 board current loop
PA0261X000020 Universal Style with 2 boards current loop
PA0261X000011 Universal Style with 1 board RS422
PA0261X000021 Universal Style with 2 boards RS422
PA0306X010 Gsite Style with 1 board RJ45 connector
PA0306X020 Gsite style with 2 boards RJ45 connector
PA0242 TS1000 Style
