SYSTEM INSTALLATION
System Installation Requirements
In preparation for the Omega JR installation, ensure that the following requirements have been met.
1. Following the manufacturer’s installation instructions, install the dispensing equipment (pumps
and data distribution boxes.)
2. Test all dispensers in stand-alone (manual) mode.
3. On dispensers which have programmable identification numbers, ensure that the numbers are
set correctly. If multiple dispensers contain the same ID number, communication conflicts will
occur.
To ensure smooth system integration, it is recommended that the petroleum equipment service
technician for the account be available to resolve dispenser-related issues.
Description of Omega JR Components
Omega JR systems are made up of the components listed below. Using this checklist, identify and
familiarize yourself with each of the components in your shipment.
C
OMPONENT
C
HECKLIST
✔ Omega JR Main Box – wall transformer is attached
✔ Brand-specific DBox(es) – as many as 2 boxes which communicate with
the appropriate brand(s) of fuel dispenser with attached wall transformer
✔ Serial cable(s) – standard 6-foot cable which connects Omega JR to DBox
✔ Omega JR Installation Manual
✔ DBox Installation Manual
Omega JR General Specifications
Physical Size 7.5” x 8.5” x 2”
Operating Temperature 32 to 120 degrees F
Storage Temperature 32 to 120 degrees F
Electrical Requirements 115VAC, 20 W Maximum (dedicated circuit)
Version 1.0 Page 2 February 2013
