Volant CRTi3-7.0 - Manual (Page 2)

1 Tool hoist rating is based on API Specification 8C; however, casing load limit is further constrained by local interaction of slip dies with casing, which must not exceed the
efficiency indicated for individual slip die sizes to avoid excess deformation. The slip to casing interaction hoist limit is calculated by multiplying the slip to pipe body load
efficiency number by the casing hoist limit found in API Bulletin 5C2. From 5C2 the pipe body yield for 9.63” x 40.0 ppf L-80 Casing is 916,000 lbs. The slip efficiency for
die 82157 used to run this casing is 75%. Therefore, the casing hoist limit is 75% x 916,000 lbs = 687,000 lbs or 343.5 tons.
2 CRTi hoist capacity must be reduced by the pressure end load during circulation.
3 Torque capacity may be limited by slip die/casing interaction. Where torque factors are provided, multiply this factor by the desired casing weight in ppf then multiply the
result by the casing yield strength to determine the slip die/casing interaction torque limit. If no value is provided, tool rating will be limiting for all standard casing grades.
4 Maximum allowable compressive load applied to the tool. Some compressive load may be reacted through the coupling. This rating does not take into account bearing
load limitations of the coupling.
5 CRTi circulation pressure capacity is generally governed by packer cup pressure capacity. Pressure capacity may be less than indicated if alternative seal arrangements
are used.
6 Overall tool length depends on seal arrangement. A typical overall tool length is 62.5” for 7.0” to 8.63” casings, 64.7” for 9.63” to 11.75” casings, 66.0” for 13.38” to
15.0” casings and 60.0” for 16.0” to 20.0” casings.
7 Maximum flow rate is based on minimizing erosion rates when using typical fluids. Erosion rates may vary based on fluid contents. Please inspect tool bore regularly.
8 Common die sizes shown. All API casing sizes and weights with drift diameter above 5.87” are available.
9 Maximum pipe weight is defined by the API Specification 5CT drift diameter of the heaviest weight casing into which the CRTi assembled with the specified die set
will fit.
10 Indicated minimum pipe weight is based on the assumption that control of average pipe inside diameter over die grip interval does not allow pipe body
area reduction less than 3.5% from nominal and additionally takes into account tool wear allowances, die penetration, casing deformation and tool stroke.
Casing Running Tools (CRTi 3-7.0)
Nom. Max. Pipe Min. Pipe Die Curv. Max. Tool Slip to Pipe Body Torque
Die P/N Pipe Size Weight 9 Weight 10 Diameter Diameter Tool Weight Load Eff. 1 Factor 3
(in) (ppf) (ppf) (in) (in) (lbs) (% Fy) (ft*lb/psi/ppf)
80928 7.0 26.0 17.0 6.4 14.4 685 77% 0.016
81062 7.0 35.0 26.0 6.16 14.4 685 80% 0.019
80986 7.63 33.7 24.0 6.93 14.4 900 71% 0.015
82279 7.63 39.0 29.7 6.76 14.4 900 76% 0.016
80987 8.63 32.0 24.0 7.8 14.4 910 80% 0.017
80824 8.63 36.0 28.0 7.7 14.4 910 80% 0.017
82118 9.63 36.0 32.3 8.78 14.4 920 73% 0.015
80825 9.63 43.5 36.0 8.6 14.4 920 74% 0.016
82157 9.63 47.0 40.0 8.53 14.4 920 75% 0.016
80988 9.63 53.5 47.0 8.39 14.4 920 76% 0.016
82021 10.75 40.5 32.75 9.9 14.4 950 68% 0.013
81323 10.75 51.0 45.5 9.7 14.4 950 66% 0.014
81085 10.75 60.7 55.5 9.51 14.4 950 68% 0.014
80833 11.75 54.0 47.0 10.72 14.4 950 56% 0.012
81955 11.75 47.0 42.0 10.84 14.4 950 55% 0.011
82070 11.75 60.7 54.5 10.62 14.4 950 58% 0.012
82327 13.38 54.5 48.0 12.48 14.4 960 45% 0.009
80828 13.38 61.0 54.5 12.36 14.4 960 47% 0.010
81064 13.38 72.0 68.0 12.19 14.4 960 49% 0.010
81504 15.0 92.5 92.5 13.65 21.0 1,040 45% 0.009
80826 16.0 65.0 65.0 15.06 21.0 1,040 25% 0.005
82440 16.0 75.0 75.0 14.95 21.0 1,040 27% 0.006
80832 18.63 87.5 87.5 17.57 21.0 1,060 22% 0.005
81292 18.63 97.7 97.7 17.47 21.0 1,060 25% 0.007
81293 18.63 111.0 111.0 17.34 21.0 1,060 27% 0.007
81991 20.0 94.0 94.0 19.39 21.0 1,250 27% 0.006
81799 20.0 111.0 111.0 19.22 21.0 1,250 27% 0.006
