Versa-Matic 3 V Series Clamped Metallic (V3) - Manual (Page 17)

v3mdlAsm-rev0314
www
.
versamatic
.
com Model V3 Metallic Bolted •
14
Composite repair Parts list - rubber
Notes:
1.) The outer diaphragm plate material is to match the water chamber material (cast iron uses SV302B or SVB307)
2.) The seat material is to match the water chamber material. In addition to this seat, (4) o-rings are needed. p/n V356T
3.) The V356T valve seat o-ring is used with metallic seats only.
4.) V=Aluminum, SV=Stainless Steel, WV=Cast Iron, H =Hastelloy
Air Valve Assembly
Item # Qty. Description
Part Number
Without Oil Bottle With Oil Bottle
1 - Valve Body ASY (includes items 5-12) V301ALF V301A
2 1 Oil Bottle N/A V301D
3 1 Oil Bottle Pipe Plug N/A V220DP
4 1 Lubricator Rod N/A V301C
5 1 Valve Body 301ALF 301A
6 1 Valve Spool V301PST
7 1 End Cap with Guide PV301R
8 1 End Cap without Guide PV301S
9 2 Snap Ring V301T
10 1 Air Valve Gasket V301B
11 1 Reducer Bushing V220AP
12 1 Air Valve Screen V220E
13 4 Air Valve Mounting Bolt V220AS
Center Section Assembly
Item # Qty. Description Part Number
14 - Center Block ASY (Includes items 15-16) V301H
15 1 Center Block 301H-F
16 5 Main Shaft O-Ring V301J
17 2 Air Chamber V303B
18 2 Center Block Gasket V301P
19 4 Bolt V303C
20 4 Cone Nut (not pictured) V222D
21 1 Muffler VTM-8
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
Versa-Rugged Versa-Dome
22 1 Main Shaft V302A
23 2 Diaphragm (See Below Material Chart) V305xx V306xx
24 2 Outer Diaphragm Plate (See Note 1 Below) V302BDC, SV302B VB307, SVB307
25 2 Inner Diaphragm Plate V302CDC V307B
26 12 Bolt V302G N/A
27 12 Washer V302GA N/A
28 2 Back-Up Washer V302E
29 4 Valve Seat (See Below Material Chart) V356xx
30 4 Valve Seat O-Ring V356T (See Note 3)
31 4 Valve Ball (See Below Material Chart) V355xx
Wet End Assembly
Item # Qty. Description
Part Number
Aluminum Cast Iron Stainless Steel Hastelloy
32 2 Water Chamber V350 WV350 SV350 HV350
33 2 Large Clamp Assembly V311 SV311
34
1 Discharge Manifold V351 WV351 SV351 HV351
1 Discharge Manifold (BSP Threaded Option) V351BSP WV351BSP SV351BSP HV351BSP
35
1 Suction Manifold V352F WV352F SV352F HV352F
1 Suction Manifold (BSP Threaded Option) V352BSPF WV352BSPF SV352BSPF HV352BSPF
36 1 Suction Manifold (Screen Mount Option) V352 N/A N/A N/A
37 1 Screen (Screen Mount Only) V353 N/A N/A N/A
38 3 Bolt (Screen Mount Only) V238A N/A N/A N/A
39 1 Hook Up Cover (Screen Mount Only) V357 N/A N/A N/A
40 4 Small Clamp Assembly V354 SV354
41 2 Bumper P34-501
Elastomer Material Specifications
Material Versa-Rugged Diaphragm P/N
Versa-Dome
Diaphragm P/N
"Ball
P/N"
Seat P/N
Neoprene V305N V306N V355N V356N
Buna Nitrile V305BN V306BN V355BN V356BN
Viton V305VT V306VT V355VT V356VT
Nordel V305ND V306ND V355ND V356ND
PTFE N/A N/A V355TF V356TF
Santoprene V305TPEXL V306TPEXL V355TPEXL V356TPEXL
Hytrel V305TPEFG V306TPEFG V355TPEFG V356TPEFG
Geolast V305G N/A N/A V356G
Aluminum N/A N/A N/A V356A (See Note 2 Below)
Carbon Steel N/A N/A N/A V356CS (See Note 2 Below)
Stainless Steel N/A N/A N/A SV356 (See Note 2 Below)
Hastelloy N/A N/A N/A HV356 (See Note 2 Below)
3: EXP
VIEW
