Versa-Matic 1 1/4 V Series Clamped Metallic (V4) - Manual (Page 15)

v4mdlAsm-rev0314
www
.
versamatic
.
com Model V4 Metallic Bolted •
12
Composite repair Parts list - PTfE
Notes:
1.) The outer diaphragm plate material is to match the water chamber material (Cast Iron Uses SV161TO)
2.) This metallic seat material is to match the water chamber material. In addition to this seat, (4) o-rings are needed. (Ref Note 3)
3.) These (4) o-rings are only used with metallic fitted seats.
4.) V=Aluminum, SV=Stainless Steel, WV=Cast Iron, H =Hastelloy
Air Valve Assembly
Item # Qty. Description
Part Number
Without Oil Bottle With Oil Bottle
1 - Valve Body ASY (includes items 4-11) V60ALF V160A
2 1 Oil Bottle N/A V160D
3 1 Lubricator Rod N/A V160C
4 1 Valve Body 60ALF 160A
5 1 Valve Spool V160PST
6 1 End Cap with Guide PV160R
7 1 End Cap without Guide PV160S
8 2 Snap Ring V160T
9 1 Air Valve Gasket V160B
10 1 Reducer Bushing V160AP
11 1 Air Valve Screen V160E
12 4 Air Valve Mounting Bolt V160AS
Center Section Assembly
Item # Qty. Description Part Number
13 - Center Block ASY (Includes items 13-15) V160H
14 1 Center Block 160H-F
15 5 Main Shaft O-Ring V220J
16 2 Air Chamber V162
17 2 Center Block Gasket V160P
18 3 Bolt V162B
19 3 Nut (not pictured) V169C
20 1 Muffler Elbow PV220G
21 1 Muffler VTM-6
Diaphragm Assembly / Elastomers
Item # Qty. Description Part Number
22 1 Main Shaft V161AT
23 2 Diaphragm (See Below Material Chart) V163TF
24 2 Back-Up Diaphragm 163TFB
25 2 Inner Diaphragm Plate V161TI
26 2 Outer Diaphragm Plate (See Note 1 Below) VB161TO, WVB161TO, SVB161TO, HVB161TO
27 2 Threaded Stud V221F
28 4 Valve Seat (See Below Material Chart) V170xx
29 4 Valve Seat O-Ring (See Below Material Chart) V170T (See Note 3)
30 4 Valve Ball (See Below Material Chart) V171xx
Wet End Assembly
Item # Qty. Description
Part Number
Aluminum Cast Iron Stainless Steel Hastelloy
31 1 Water Chamber V165 WV165 SV165 HV165
32 2 Large Clamp Assembly V164 SV164
33
1 Discharge Manifold V166 WV166 SV166 HV166
1 Discharge Manifold (BSP Option) V166BSP WV166BSP SV166BSP HV166BSP
34
1 Suction Manifold (Footed Option) V167F WV167 SV167 HV167
1 Suction Manifold (BSP Footed Option) V167FBSP WV167BSP SV167BSP HV167BSP
35 1 Suction Manifold (Screen Mount Option) V167 N/A N/A N/A
36 1 Screen (Screen Mount Only) V168 N/A N/A N/A
37 4 Bolt (Screen Mount Only) P34-110 N/A N/A N/A
38 4 Washer V302GA N/A N/A N/A
39 4 Small Clamp Assembly V169 SV169
Elastomer Material Specifications
Material "Ball P/N" Seat P/N
PTFE V171TF V170TF
Aluminum N/A V170A (See Note 2 Below)
Carbon Steel N/A V170CS (See Note 2 Below)
Stainless Steel V171SS SV170 (See Note 2 Below)
Hastelloy N/A HV170 (See Note 2 Below)
MODEL SPECIFIC
3: EXP
VIEW
