• Model E2 3-A Sanitary
Composite Repair Parts List
Notes:
1.) The inner diaphragm plate material is to match the air chamber material (Ref. Note 3)
SV=Stainless Steel, NP=Nickle Plated
Air Valve Assembly
Item # Qty. Description
Part Number
Nickle Plated
1 1 Valve Body (includes items 2-11) 031.V002.332
2 1 Valve Body 095.V001.332
3 1 Valve Body Gasket P24-202
4 1 Valve Sleeve 755.V006.148
5 6 O-ring 560.206.360
6 1 Valve Spool Assembly (Includes items 7) 775.V001.000
7 6 Glyde Ring Assembly P34-204F
8 1 Air Valve Screen P24-210
9 2 End Cap Gasket P24-205
10 2 End Cap SP34-300
11 13 Mounting Screws (8 included on item 1) S1001
Center Section Assembly
Item # Qty. Description
Part Number
Nickle Plated
12 1 Center Block Assembly (Includes item 13 & 14) P24-401NP
13 2 Bearing Sleeve P31-403
14 2 Main Shaft O-Ring P24-403
15 2 Air Chamber 196.V002.332
16 2 Air Chamber Gasket 360.V001.360
17 8 Bolt SP24-110
18 1 Pilot Sleeve Assembly (include item 19) 755.V002.000
19 6 O-ring 560.101.358
20 1 Retaining Ring 675.037.080
21 1 Pilot Spool Assembly (Includes item 22) 775.V002.000
22 8 O-ring 560.023.358
23 1 Stand Attachment P24-651NP
24 2 Stand Attachment Pin P29-654
25 1 Stand SP29-650CP
26 1 Stand Locking Pin P29-652
27 1 Muffler 530.033.000
Diaphragm Assembly / Elastomers
Item # Qty. Description Part Number
28 1 Main Shaft P24-103F
29 2 Diaphragm (See Material Chart Below) V224F
30 2 Bumper Washer P24-501
31 4 Valve Ball (See Material Chart Below) V241TF
32 4 Manifold Tee Seal V275TF
33 4 Manifold Elbow Seal V276TF
Wet End Assembly
Item # Qty. Description Part Number
34 2 Water Chamber D29-235
35 4 Large Clamp Half SV230A
36 4 Bolt SV230C
37 4 Wing Nut FG30D
38 2 ManifoldTee D29-238
39 4 Manifold Elbow D29-237
40 4 Ball Cage D29-252
41 4 Manifold Elbow Clamp V275A
42 4 Manifold Tee Clamp V276A
43 1 Leak Detector P29-800
44 2 Leak Detector Probe P29-804
