• Model E2 Metallic Food Processing
Composite Repair Parts List - PTFE Fitted
Notes:
1.) In addition to this seat, (4) o-rings are needed.
2.) These (4) o-rings are only used with metallic fitted seats.
3.) The inner diaphragm plate material is to match the air chamber material (Ref. Note 4)
4.) SV=Stainless Steel, NP=Nickle Plated
Air Valve Assembly
Item # Qty. Description
Part Number
Stainless Steel Nickle Plated
1 1 Valve Body (includes items 2-11) 031.V002.110 031.V002.332
2 1 Valve Body 095.V001.110 095.V001.332
3 1 Valve Body Gasket P24-202
4 1 Valve Sleeve 755.V006.148
5 6 O-ring 560.206.360
6 1 Valve Spool Assembly (Includes items 7) 775.V001.000
7 6 Glyde Ring Assembly P34-204F
8 1 Air Valve Screen P34-210 P24-210
9 2 End Cap Gasket P24-205
10 2 End Cap SP34-300
11 13 Mounting Screws (8 included on item 1) S1001
Center Section Assembly
Item # Qty. Description
Part Number
Stainless Steel Nickle Plated
12 1 Center Block Assembly (Includes item 13 & 14) SP24-400 P24-401NP
13 2 Bearing Sleeve P31-403
14 2 Main Shaft O-Ring P24-403
15 2 Air Chamber 196.V002.110 196.V002.332
16 2 Air Chamber Gasket P24-109A 360.V001.360
17 8 Bolt SP24-110
18 1 Pilot Sleeve Assembly (include item 19) 755.V002.000
19 6 O-ring 560.101.358
20 1 Retaining Ring 675.037.080
21 1 Pilot Spool Assembly (Includes item 22) 775.V002.000
22 8 O-ring 560.023.358
23 1 Muffler 560.033.000
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
PTFE Two Piece Fusion
24 1 Main Shaft P24-102 P24-103F
25 2 Diaphragm V224TF V224F
26 2 Back-Up Diaphragm V224TFB N/A
27 2 Inner Diaphragm Plate (see note 3) V221TINP, SV221TI N/A
28 2 Bumper Washer P24-501
29 2 Outer Diaphragm Plate SV221TOFG N/A
30 4 Valve Seat (See Below Material Chart) V240xx
31 4 Valve Seat O-Ring V240T (See note 1)
32 4 Valve Ball V241TF
Wet End Assembly
Item # Qty. Description Part Number
33 2 Water Chamber SV235FG
34 4 Large Clamp Half SV230A
35 4 Bolt SV230C
36 4 Wing Nut FG30D
37 1 Discharge Manifold SV236FG
38 1 Suction Manifold SV237FFG
39 8 Small Clamp Half SV239A
40 8 Bolt SV239B
41 8 Wing Nut FG39C
42 2 Diaphragm Seal Tape Kit (Not Pictured) 720.V005.000
Parts For Rubber Mounting Feet
Item # Qty. Description Part Number
43 4 Foot, Mounting 350.001.360
44 4 Capscrew, Hex Head 170.061.115
45 4 Nut, Hex 545.005.115
46 4 Lockwasher 900.005.115
47 4 Flatwasher 901.005.115
Material Specifications
Material "Ball P/N" Seat P/N
PTFE V241TF V240TF
Stainless Steel N/A SV240 (See Note 1 Below)
