• Model E2 Metallic Food Processing
Composite Repair Parts List - TPE Fitted
Notes:
1.) The inner diaphragm plate material is to match the air chamber material (Ref. Note 4)
Air Valve Assembly
Item # Qty.
Description
Part Number
Stainless Steel
Nickle Plated
1
1
Valve Body (includes items 2-11)
031.V002.110
031.V002.332
2
1
Valve Body
095.V001.110
095.V001.332
3
1
Valve Body Gasket
P24-202
4
1
Valve Sleeve
755.V006.148
5
6
O-ring
560.206.360
6
1
Valve Spool Assembly (Includes items 7)
775.V001.000
7
6
Glyde Ring Assembly
P34-204F
8
1
Air Valve Screen
P34-210
P24-210
9
2
End Cap Gasket
P24-205
10
2
End Cap
SP34-300
11
13
Mounting Screws (8 included on item 1)
S1001
Center Section Assembly
Item # Qty.
Description
Part Number
Stainless Steel
Nickle Plated
12
1
Center Block Assembly (Includes item 13 & 14)
SP24-400
P24-401NP
13
2
Bearing Sleeve
P31-403
14
2
Main Shaft O-Ring
P24-403
15
2
Air Chamber
196.V002.110
196.V002.332
16
2
Air Chamber Gasket
P24-109A
360.V001.360
17
8
Bolt
SP24-110
18
1
Pilot Sleeve Assembly (include item 19)
755.V002.000
19
6
O-ring
560.101.358
20
1
Retaining Ring
675.037.080
21
1
Pilot Spool Assembly (Includes item 22)
775.V002.000
22
8
O-ring
560.023.358
23
1
Muffler
560.033.000
Diaphragm Assembly / Elastomers
Item # Qty.
Description
Part Number
Versa-Rugged
Versa-Dome
FDA Hytrel
FDA Santoprene
FDA Hytrel
FDA Santoprene
24
1
Main Shaft
P24-103
P24-103
P24-103
25
2
Diaphragm
V224TPEFG
V224TPEXLFG
V225TPEFG
V225TPEXLFG
26
2
O-ring
V221D
N/A
N/A
N/A
27
2
Inner Diaphragm Plate (See Note 1 Below)
V221BNP, SV221B
V221BNP
V226BNP, SV226B
V226BNP
28
2
Bumper Washer
N/A
P24-501
P24-501
N/A
29
2
Outer Diaphragm Plate
SVB221FG
SVB226FG
SVB226FG
SVB226FG
30
4
Valve Seat (See Material Chart Below)
V240TPEFG
V240TPEXLFG
V240TPEFG
V240TPEXLFG
31
4
Valve Seat O-Ring
V240T (See Note 2)
32
4
Valve Ball
V241TPEFG
V241TPEXLFG
V241TPEFG
V241TPEXLFG
Wet End Assembly
Item # Qty.
Description
Part Number
33
2
Water Chamber
SV235FG
34
4
Large Clamp Half
SV230A
35
4
Bolt
SV230C
36
4
Wing Nut
FG30D
37
1
Discharge Manifold
SV236FG
38
1
Suction Manifold
SV237FFG
39
8
Small Clamp Half
SV239A
40
8
Bolt
SV239B
41
8
Wing Nut
FG39C
Parts For Rubber Mounting Feet
Item # Qty.
Description
Part Number
42
4
Foot Mounting
350.001.360
43
4
Capscrew, Hex Head
170.061.115
44
4
Nut, Hex
545.005.115
45
4
Lockwasher
900.005.115
46
8
Flatwasher
901.005.115
Material Specifications
Material
"Ball P/N"
PTFE
V241TF
Stainless Steel
N/A
MODEL SPECIFIC
3: EXP
VIEW
