7/02 Page
4
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.They
are readily available from most Warren Rupp
distributors. The pump owner may prefer to
maintain a limited inventory of these parts in
his own stock to reduce repair downtime to
a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000... Assembly, sub-assembly; and some purchased items
010... Cast Iron
015... Ductile Iron
080... Carbon Steel , AISI B-1112
100... Alloy 10
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
114... 303 Stainless Steel
115... 302/304 Stainless Steel
117... 440-C Stainless Steel (Martensitic)
120... 416 Stainless Steel (Wrought Martensitic)
123... 410 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
149... 2024-T4 Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
152... 2024-T4 Aluminum (2023-T351)
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
165... Cast Bronze, 85-5-5-5
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
310... PVDF Coated
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —
Duro 40D + /-5. Color coded: RED
357... Rupplon (Urethane Rubber)
Color coded: PURPLE (Injection mold)
358... Rupplon (Urethane Rubber)
Color coded: PURPLE (Some Applications)
(Compression Mold)
360... Buna-N Rubber. Color coded: RED
363... Viton (Fluorel). Color coded: YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Neoprene. Color coded: WHITE
370... Butyl Rubber. Color coded: BROWN
405... Cellulose Fibre
408... Cork and Neoprene
425... Compressed Fibre
465... Fibre
500... Delrin 500
505... Acrylic Resin Plastic
540... Nylon
550... Polyethylene
555... PVC
570... Rulon II
580... Ryton
590... Valox
591... Nylatron G-S
592... Nylatron NSB
600... PTFE (virgin material) Tetrafluoracarbon (TFE)
601... PTFE (Bronze and moly filled)
602... Filled PTFE
603... Blue Gylon
604... PTFE — Diaphragm
Delrin, Viton and Hytrel are registered tradenames of
E.I. DuPont.
Gylon is a registered tradename of Garlock, Inc.
Nylatron is a registered tradename of Polymer Corporation.
Ryton is a registered tradename of Phillips Chemical Co.
Valox is a registered tradename of General Electric Co.
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
28 406-001-000 Handle Assembly 1
29 866-007-162 Male Connector 2
30 312-007-180 Elbow 1
31 200-004-330 Muffler Clamp 1
32 115-004-080 Bracket 1
33 254-004-000 Coupler 1
35 312-006-000 Elbow, Motor 1
36 312-004-162 Elbow, Motor Housing 1
37 200-005-115 Hose Clamp 2
38 427-006-000 Hose, ¾ I.D. 1
39 675-006-000 Retaining Ring 1
40 675-005-000 Retaining Ring 1
41 675-003-080 Retaining Ring 2
42 360-004-440 Gasket 6 Minimum
43 560-013-360 O-Ring 1
44 560-007-360 O-Ring 1
45 560-012-360 O-Ring 1
46 560-009-360 O-Ring 2
47 560-006-360 O-Ring 1
48 560-008-360 O-Ring 1
49 560-005-360 O-Ring 1
51 618-005-330 Pipe Plug ½" NPT 1
52 312-008-335 Street Elbow 1
53 170-033-330 Capscrew 4
54 170-006-330 Capscrew 12
55 170-005-330 Capscrew 3
56 546-001-115 Cap Nut 2
57 170-002-330 Capscrew 1
58 545-003-330 Hex Nut 2
59 900-001-330 Lock Washer 5
60 901-014-180 Washer, Sealing 3
61 901-009-330 Flat Washer 2
62 900-005-330 Lock Washer 11
63 170-007-115 Capscrew 2
64 901-024-180 Sealing Washer 2
65 861-001-000 Metering Tube Assembly 1
66 312-003-000 Elbow 1
67 866-006-162 Male Connector 2
68 430-009-155 Governor Housing 1
69 560-011-360 O-Ring 1
70 670-002-162 Retainer, Seal Ring 1
71 675-004-000 Ring, Retainer 1
72 675-002-165 Seal Ring 1
73 740-002-115 Shim (.010) 3
74 740-003-115 Shim (.030) 2
75 901-005-330 Flat Washer 3 /
8
" 4
76 170-008-115 Capscrew 10
77 860-022-180 Tubing, Soft Copper 2
78 170-063-330 Capscrew, Hex Head 1
535-002-000 (NOT SHOWN) 1
705-002-000 (NOT SHOWN) 4
