ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 180-002-155 Volute Casing 1
2 258-003-010 Suction Cover 1
3 444-002-010 Impeller 1
4 612-002-080 Wear Plate 1
5 430-008-155 Motor Housing 1
6 775-002-155 Filter Spool 1
7 800-003-330 Strainer Assembly 1
8 430-007-155 Intermediate Housing 1
9 730-009-120 Shaft 1
10 430-010-150 Bearing Housing 1
11 720-002-000 Shaft Seal 1
12 070-002-000 Ball Bearing 1
13 755-001-000 Sleeve 2
14 552-001-000 Oil Seal 1
15 670-004-162 Seal Retainer 1
16 914-002-330 Governor Weight 2
17 590-002-115 Governor Pin 1
18 675-001-115 Retaining Ring 2
19 775-003-162 Governor Spool 1
20 780-002-115 Governor Spring 1
21 670-003-115 Spring Retainer 1
22 255-001-000 Coupling Assembly 1
22-1 770-013-000 Spider Insert (see Figure 6) 1
23 320-002-000 Filter Element 1
25 770-001-162 Spacer 1
26 525-003-000 Air Motor Assembly 1
Consists of:
26-1
AD-665 Body 1
26-2 AD-666 End Plate, Drive 1
26-3 AD-651 End Plate, Dead 1
26-4 AD-652 Rotor Assembly 1
26-5 AD-691 Vane 4
26-6 AD-692 Spring, Vane 4
26-7 AD-655-A Push Pin 2
26-8 AD-638-A Bearing, Drive 1
26-9 AC-437 Bearing, Dead 1
26-10 AC-849 Seal, Shaft 1
26-11 AB-162 Pin, Dowel 5
26-12 AD-641-F Gasket, End Plate 2
26-13 AD-642-A End Cap, Dead 1
26-14 AD-643 End Cap, Dead 1
26-15 AD-644 End Cap, Gasket 1
26-16 560-003-360 O-Ring 1
27 530-001-000 Muffler Assembly 1
Consists of:
27-1
560-010-360 O-Ring 2
27-2 538-001-555 Nipple 1
27-3 860-009-150 Tube 1
27-4 165-001-155 Cap, Upper 1
27-5 165-002-155 Cap, Lower 1
27-6 685-001-080 Rod 1
27-7 546-002-115 Cap Nut 1
27-8 901-024-180 Sealing Washer 2
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.They
are readily available from most Warren Rupp
distributors. The pump owner may prefer to
maintain a limited inventory of these parts in
his own stock to reduce repair downtime to
a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
SERVICE AND OPERATING MANUAL
Model SMA3-A
SLUDGEMASTER ®
MATERIAL CODES
The Last 3 Digits of Part Number
000... Assembly, sub-assembly; and some purchased items
010... Cast Iron
015... Ductile Iron
080... Carbon Steel , AISI B-1112
100... Alloy 10
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
114... 303 Stainless Steel
115... 302/304 Stainless Steel
117... 440-C Stainless Steel (Martensitic)
120... 416 Stainless Steel (Wrought Martensitic)
123... 410 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
149... 2024-T4 Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
152... 2024-T4 Aluminum (2023-T351)
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
165... Cast Bronze, 85-5-5-5
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
310... PVDF Coated
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —
Duro 40D + /-5. Color coded: RED
357... Rupplon (Urethane Rubber)
Color coded: PURPLE (Injection mold)
358... Rupplon (Urethane Rubber)
Color coded: PURPLE (Some Applications)
(Compression Mold)
360... Buna-N Rubber. Color coded: RED
363... Viton (Fluorel). Color coded: YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Neoprene. Color coded: WHITE
370... Butyl Rubber. Color coded: BROWN
405... Cellulose Fibre
408... Cork and Neoprene
425... Compressed Fibre
465... Fibre
500... Delrin 500
505... Acrylic Resin Plastic
540... Nylon
550... Polyethylene
555... PVC
570... Rulon II
580... Ryton
590... Valox
591... Nylatron G-S
592... Nylatron NSB
600... PTFE (virgin material) Tetrafluoracarbon (TFE)
601... PTFE (Bronze and moly filled)
602... Filled PTFE
603... Blue Gylon
604... PTFE — Diaphragm
