520-377-000 Rev C 8/02 Model SPA15 and SPA15-BSP Design Level 3 Page 3
VERSA-MATIC PUMP, A unit of IDEX Corporation • 6017 Enterprise Drive • Export, PA 15632 USA • (724) 327-7867 Fax (724) 327-4300
SERVICE AND OPERATING MANUAL
Porta-Matic Model SPA153
Model SPA15-BSP3
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 710-004-330 Screw, Self-Tapping 3
2 258-017-157 Cover, Motor 1
3 545-005-330 Hex Nut 1
4 405-001-000 Handle 1
5 543-001-162 Nut, Gland 2
6 770-007-162 Spacer, Gland 2
7 675-016-360 Ring, Sealing 2
8 545-004-330 Hex Nut 4
9 900-004-330 Lock Washer 4
10 807-011-330 Stud 4
11 270-001-000 Circuit Breaker 1
12 170-028-330 Capscrew, Hex Head 4
13 900-001-330 Lock Washer 8
14 360-001-440 Gasket, Casing 5
15 170-003-115 Capscrew, Hex Head 4
16 444-001-010 Impeller 1
17 740-001-115 Shim As. Req.*
18 258-001-157 Cover, Suction 1
19 612-001-156 Plate, Strainer 1
20 700-001-330 Screen, Strainer 1
21 181-001-155 Casing, Volute, 1½ NPT 1
181-001-155E Casing, Volute, 1½ BSPT (tapered) 1
22 560-022-360 O-Ring 2
23 720-005-000 Seal 1
24 860-011-150 Tube, Casing 1
25 525-005-000 Motor 1
26 200-003-000 Clamp, Cable 1
27 706-007-330 Screw, Machine 1
28 150-036-000 Power Cable Assembly Complete 1
29 900-002-330 Washer, Lock 1
30 510-003-000 Lug, Compression 1
31 240-001-000 Nut, Insulated Wire 1
For Models SPA153F, 12 DC3 and SPa15BSP3F, 12DC3: (Not Shown)
10 807-011-330 Stud 2
807-012-330 Stud (replaces 2 807-011-330) 2
325-001-330 Foot, Mounting 2
547-001-330 Stop Nut 5/16-18Vac 2
904-001-330 Washer 2
Service Items: (Not Shown)
526-001-000 Brush 2 per motor
475-220-000 Design Level 2 to Design Level 3
Conversion Kit
* Typically 7
** Items 30 & 45 available as a kit #475-132-000
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren
Rupp distributors. The pump owner may
prefer to maintain a limited inventory of these
parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000…Assembly, sub-assembly; and some purchased Items
010…Cast Iron
012…Powered Metal
015…Ductile Iron
020…Ferritic Malleable Iron
025…Music Wire
080…CarbonSteel AISI B-1112
100…Alloy 20
110…Alloy Type 316 Stainless Steel
111…Alloy Type 316 Stainless Steel (Electro Polished)
112…Alloy “C”
113…Alloy Type 316 Stainless Steel (Hand Polished)
114…303 Stainless Steel
115…302/304 Stainless Steel
117…440-C Stainless Steel (Martensitic)
120…416 Stainless Steel (Wrought Martensitic)
123…410 Stainless Steel (Wrought Martensitic)
148…Hardcoat Anodized Aluminum
149…2024-T4 Aluminum
150…6061-T6 Aluminum
151…6063-T6 Aluminum
152…2024-T4 Aluminum (2023-T351)
154…Almag 35 Aluminum
155 or 156…356-T6 Aluminum
157…Die Cast Aluminum Alloy #380
158…Aluminum Alloy SR-319
159…Anodized Aluminum
162…Brass, Yellow, Screw Machine Stock
165…Cast Bronze, 85-5-5-5
166…Bronze SAE 660
170…Bronze, Bearing Type, Oil Impregnated
180…Copper Alloy
310…Kynar Coated
330…Zinc Plated Steel
331…Chrome Plated Steel
332…Electroless Nickel Plated
335…Galvanized Steel
336…Zinc Plated Yellow Brass
337…Silver Plated Steel
340…Nickel Plated
342…Filled Nylon
354…Injection Molded #203-40 Santoprene
- Duro 40D ± 5; Color: RED
355…Thermoplastic Elastomer
356…Hytrel
357…Rupplon (Urethane Rubber) Color coded:PURPLE
358…Rupplon (Urethane Rubber)
Color coded:PURPLE
(Some Applications, Compression Mold)
359…Urethane Rubber
360…Buna-N Rubber Color coded: RED
361…Buna-N
363…Viton (Fluorel) Color coded: YELLOW
364…E.P.D.M. Rubber Color coded: BLUE
365…Neoprene Rubber Color coded: GREEN
366…Nitrile, USDA Approved
368…EPDM, USDA Approved
List continued next page
