Composite repair parts list, Model specific – Versa-Matic 3 Bolted Metallic Ball Valve Pumps (RE3) User Manual
Page 17
re3mdlAsm-rev0314
www
.
versamatic
.
com
3: EXP
VIEW
Model RE3 Metallic Bolted •
14
Composite Repair Parts list
AIR VALVE ASSEMBLY
Item
Description
Qty
Standard:
Aluminum
Air Valve Assembly
1
P126-0036
(Includes items 1-10)
1
Valve Body
1
P126-0003
2
Valve Spool
1
P126-0063
3
Valve Spool Glyd Ring
4
P34-204F
4
End Cap
1
P34-300
5
End Cap Gasket
2
P24-205
6
Adapter, Air Inlet
1
P126-0004
7
Tube, Air Inlet Seal
1
P126-0005
8
Air Inlet O-Ring
2
560.024.360
9
Valve Gasket
1
P24-202
10
Valve Cap Screw
11
S1001
11
Valve Cap Screw
2
P24-209
AIR END ASSEMBLY
Item
Description
Qty
Standard:
Aluminum
12
Center Block
1
P126-0020
13
Main Shaft Bushing
1
P34-402
14
Air Chamber, Left
1
P126-0021
15
Air Chamber, Right
1
P126-0022
16
Air Chamber Gasket
2
P79-109
17
Air Chamber Bolt
8
P24-110
18
Bushing
2
P34-105
19
Pilot Shaft
1
P34-104
20
Pilot Shaft Spacer
5
P24-106
21
Pilot Shaft O-Ring
6
P24-107
22
Stop Nut
2
P24-108
24
Mounting Bracket Left
1
115.V005.159
25
Mounting Bracket Right
1
115.V006.159
26
Retainer Plate
2
P126-0024
27
Retainer Foam
2
P126-0011
28
Retainer O-Ring
2
560.203.360
29
Retainer Cap Screw
8
P126-0032
30
AirVantage Unit
1
P126-0044
31
AirVantage Unit Cap Screw
4
170.121.330
32
AirVantage Cable
1
P126-0042
33
AirVantage Sensor
1
P126-0039
34 AirVantage Unit Face Seal O-Ring 1
560.011.360
35
AirVantage Connector Plate
1
P126-0055
36
AirVantage Connector Plate O-Ring 1
V110BN
37
Check Valve
1
894.014.000
37a Check Valve Cartridge
1
031.203.000
38
Check Valve Cap Screw
4
171.100.115
39
Check Valve O-Ring
1
560.200.360
40
Muffler
1
530.038.000
41
Muffler Adapter
1
312.045.335
42
Muffler Nipple
1
538.110.335
MODEL SPECIFIC
