Composite repair parts list - aluminum, Model specific – Versa-Matic 2 Bolted Metallic Hazardous Service Ball Valve (RE2) User Manual
Page 16
re2mdlAsmATEX-rev0614
www
.
versamatic
.
com
3: EXP
VIEW
13
• Model RE2 Metallic Bolted
Composite Repair Parts List - Aluminum
AIR VALVE ASSEMBLY
Item
Qty
Description
Standard: Aluminum
1
Air Valve Assembly (Includes items 1-11)
P126-0085
1
1
Valve Body
P126-0003
2
1
Valve Spool
P126-0063
3
4
Valve Spool Glyd Ring
P34-204F
4
1
End Cap
P34-300
5
2
End Cap Gasket
P24-205
6
1
Adapter, Air Inlet
P126-0070
7
1
Tube, Air Inlet Seal
P126-0005
8
2
Air Inlet O-ring
560.024.360
9
1
Valve Gasket
P24-202
10
11
Valve Cap Screw
S1001
11
2
Valve Cap Screw
P24-209
AIR END ASSEMBLY
Item
Qty
Description
Standard: Aluminum
12
1
Center Block
P126-0001
13
1
Main Shaft Bushing
P24-402
14
1
Air Chamber, Left
P126-0016
15
1
Air Chamber, Right
P126-0017
16
2
Air Chamber Gasket
P79-109
17
8
Air Chamber Bolt
P24-110
18
2
Bushing
P24-105
19
1
Pilot Shaft
P24-104
20
5
Pilot Shaft Spacer
P24-106
21
6
Pilot Shaft O-Ring
P24-107
22
2
Stop Nut
P24-108
24
1
Mounting Bracket Left
115.V013.159
25
1
Mounting Bracket Right
115.V014.159
26
2
Retainer Plate
P126-0010
27
2
Retainer Foam
P126-0011
28
2
Retainer O-Ring
560.203.360
29
8
Retainer Cap Screw
P126-0032
30
1
AirVantage Unit
P126-0081
31
4
AirVantage Unit Cap Screw
170.125.330
33
1
AirVantage Sensor
P126-0035 (Standard)
P126-0059 (PTFE Diaphragm)
34
1
AirVantage Unit Face Seal O-ring
560.011.360
35
1
AirVantage Connector Plate
P126-0055
36
1
AirVantage Connector Plate O-ring
V110BN
37
1
Check Valve
894.014.000
37a
1
Check Valve Cartridge
031.206.000
38
4
Check Valve Cap Screw
171.100.115
39
1
Check Valve O-Ring
560.200.360
40
1
Muffler
530.038.000
41
1
Muffler Adapter
312.045.335
42
1
Muffler Nipple
538.110.335
DIAPHRAGM ASSEMBLY
Item
Qty
Description
Dome
Rugged
PTFE
43
2
Main Shaft O-Ring
P24-403
P24-403
P24-403
44
1
Main Shaft
P24-103
P24-103
P24-102
45
2
Inner Diaphragm Plate
P126-0014
P126-0015
P126-0058
46
2
Outer Diaphragm Plate
VB226
VB221
V221TO
47
2
Diaphragm
V225XX
(Refer to Materials Chart)
V224XX
(Refer to Materials Chart)
V224TF-FB
48
2
Bumper Washer
P24-501
P24-501
P24-501
49
2
Stud
N/A
N/A
V221F
50
2
Back-Up Diaphragm
N/A
N/A
V224TFB
51
2
Probe Tip
846.001.167
846.001.167
N/A
52
2
O-Ring Probe Tip
560.201.360
560.201.360
N/A
53
2
O-Ring Sensor
560.033.360
560.033.360
N/A
MODEL SPECIFIC
