• Model RE2 Metallic Bolted
Caution! Whenever troubleshooting or performing any
repairs on any IDEX AODD equipment, always remove air
supply line to the pump and wear proper personal protec-
tive equipment.
LED OUTPUT FOR AirVantage UNIT
STATE LED OUTPUT
Startup/Settle/Deadhead Solid
Standby/Low Flow 1 Second ON / 1 Second OFF
Learn Mode 0.1 Seconds ON / 0.1 Seconds OFF
Seek/Optimize 1 Second ON / 0.1 Seconds OFF
Steady State/Air Savings OFF / ON in rhythm with Cycle
Rate of Pump
AirVantage LED DOES NOT LIGHT UP AT ALL
What to Check:
• Make sure power switch on the control module is turned
on, (depressed to the left)
• Make sure air is being supplied to pump or make sure 110
VAC unit has power being supplied to it
Corrective Action:
• Cycle power switch off/on
• Unplug patch cable and cycle power switch off/on
• Consult Factory After Sales Support team
AirVantage LED LIGHTS UP AND STAYS ON SOLID
What to Check:
• Make sure patch cable is plugged in and locked
Corrective Action:
• Consult Factory After Sales Support team
VALVE FIRES ONCE AND IMMEDIATELY RESETS
Corrective Action:
• Consult Factory After Sales Support team
VALVE LED NEVER LEAVES SEEK MODE - AirVan-
tage LED PULSING IN TIME TO PUMP, BUT VALVE
NOT ACTUATING AND THE PUMP IS NOT SAVING
AIR
Corrective Action:
• Consult Factory After Sales Support team
UNEXPECTED OPERATING CONDITION (AIR SAV-
INGS OR FLOW RATE)
What to Check:
• Check for varying environmental pumping conditions
(changing head or suction)
• Check ice buildup in exhaust area
• Inspect sleeve and spool for damage
Corrective Action:
• Consult Factory After Sales Support team
PUMP CYCLING IS UNSTABLE OR ERRATIC
What to Check:
• Run pump without AirVantage and check pump operation
• Make sure patch cable plug is connected and locked
• Make sure power wire connectors are tight
Corrective Action:
• Consult Factory After Sales Support team
PUMP RUNNING SLOWLY
What to Check:
• Run pump without AirVantage and check operation
• Cycle the power off/on to the control module to
reset controller
• Check ice buildup in exhaust area
• Inspect sleeve and spool set for damage
Corrective Action:
• Consult Factory After Sales Support team
• Cycle the power switch on the control module off/on
Do not open when an
explosive atmosphere
may be present.
WARNING
S u b s t i t u t i o n o f
components may
impair intrinsic safety.
WARNING
AirVantage Troubleshooting Guide
